Relais Liste DL/NL/OZ

10m / 2m / 70cm / 23cm / 13cm DE / NL / DK

Stand 05.05.2018

Gelb Markierte sind  von JO43GI zu Erreichen

Sortiert nach Frequenz

DM0MAX JO42IG 29.62000 29.52000 -0.1 FM Wiehengebirge

CTCSS TX 88,5 RX

oder 1750Hz

SQL offen min 3sec
DB0DHH JO44NI 29.63000 29.53000 -0.1 FM Drage
DB0ABB JO41UO 29.63000 29.53000 -0.1 FM Adelebsen
DB0ARB JN69NC 29.64000 29.54000 -0.1 FM Großer Arber
DB0SKY JO31RH 29.64000 29.54000 -0.1 FM Hagen
PI6NLT JO33KH 29.64000 29.54000 -0.1 FM Farmsum CTCSS: 82,5 Hz
DB0TVH JO42UJ 29.65000 29.55000 -0.1 FM Hannover CTCSS 88,5
DB0BHV JO43HO 29.66000 29.56000 -0.1 FM Bremerhaven
OZ0REU JO65FP 29.66000 29.56000 -0.1 FM Hvidovre 82.5 82.5 Analog
DF0MOT JO40FF 29.67000 29.57000 -0.1 FM

Gr. Feldberg im

Taunus

 mit 4 Sekunden PTT öffnen,
DM0MGB JO52TD 29.68000 29.58000 -0.1 FM Magdeburg
DF0HHH JO43WJ 29.69000 29.59000 -0.1 FM Rosengarten

E 76975, TX-CTCSS=67,0 Hz,

FM-Narrow (TX+RX=3 kHz!),

Livestream


PI6NOS JO22NF 29.69000 29.59000 -0.1 FM

Hilversum

Niederlande


DB0WTL JN49QC 29.69000 29.59000 -0.1 FM Loewenstein - Wasserturm zur Zeit außer Betrieb (03.2017)
PI6TEN JO22NF 29.69000 29.59000 -0.1 FM Hilversum EL#512885
DB0SLF JO50QP 144.80000 144.80000 0 FM Saalfeld Saale APRS
DB0PDM JO62MI 144.80000 144.80000 0 FM Potsdam APRS, 1200 Bd
DB0MIA-C JO54IH 144.81250 144.81250 0 DStar

Hohwachter

Bucht

 Hotspot
DO0TPB-C JO53HJ 144.81250 144.81250 0 DStar Basedow

Multimode Relais MMDVM DMR,

DStar, C4FM
DO0TPB JO53HJ 144.81250 144.81250 0 DMR Basedow

Multimode Relais MMDVM DMR,

DStar, C4FM
DO0TPB JO53HJ 144.81250 144.81250 0 C4FM Basedow

Multimode Relais MMDVM DMR,

DStar, C4FM
DB0FTC JN49BO 144.81250 144.81250 0 FM

Quirnheim

Solarpark

 simplex
DB0FTC JN49BO 144.81250 144.81250 0 C4FM

Quirnheim

Solarpark

 simplex
DB0IR-C JO44QR 144.82500 144.82500 0 DStar Handewitt Hotspot
DB0LW JO62OC 144.82500 144.82500 0 C4FM Luckenwalde C4FM/WiresX Hotspot Simplex
DB0HE JO31NO 144.82500 144.82500 0 DStar Herten

Reflektor XLX518C

Open D-Star voreingestellt
DM0HHW-C JO53AN 144.83750 144.83750 0 DStar HH-Wandsbek Hotspot
DM0BAM-C JO43KC 144.83750 144.83750 0 DStar Horn-Lehe
DM0HAT-C JO54LD 144.85000 144.85000 0 DStar Grömitz Hotspot
DB0HPA JO43SV 144.85000 144.85000 0 DStar Laegerdorf Hotspot
DB0PLN-C JO54FD 144.86250 144.86250 0 DStar Plön Hotspot
DM0RAM-C JO53AI 144.86250 144.86250 0 DStar Ramelsloh
DO0GUD-C JO53JN 144.87500 144.87500 0 DStar Gudow Hotspot
DM0TR JO54CB 144.88750 144.88750 0 DStar Trappenkamp
PI1DSE-C JO21SK 144.90000 144.90000 0 FM

Eindhoven

Niederlande

 simplex
DB0MDW-C JO53FT 144.93750 144.93750 0 DStar Meddewade Hotspot
DB0KOE JO30LW 144.93750 144.93750 0 DStar Köln
PI1HWB-C JO21JN 144.98750 144.98750 0 FM

Breda

Niederlande

 simplex
DB0HAS JO50HA 145.23750 145.23750 0 FM Zeil am Main SVXLink-Simplex-Gateway
DB0HUS JO44ML 145.28750 145.28750 0 FM Husum 226916
DB0BRO JO51HT 145.57500 144.97500 -0.6 C4FM Brocken Harz

Brockenhaus 88.5Hz

C4FM-FM Multimode

Pilotton 144.925
DB0EAT-C JO43VR 145.57500 144.97500 -0.6 DStar Ellerhoop
PI3UTR JO22MA 145.57500 144.97500 -0.6 FM

Ijsselstein

Niederlande


DB0ULR JN58SC 145.57500 144.97500 -0.6 FM München Solln FM NXDN
DB0DTR JN39GS 145.57500 144.97500 -0.6 DStar Trierweiler 88,5 Hz for FM-Use
DB0PIB JO71EC 145.57500 144.97500 -0.6 FM Großer Picho
DB0WUN JO60BA 145.57500 144.97500 -0.6 DStar Marktredwitz
DB0DBN JO30OQ 145.58750 144.98750 -0.6 C4FM

Königswinter

Oelberg


DB0PAS JN68SO 145.58750 144.98750 -0.6 DStar Passau-Thrynau
DB0DMB-C JO54CJ 145.58750 144.98750 -0.6 DStar Laboe
DB0POB JN58QP 145.58750 144.98750 -0.6 DStar Pobenhausen
DB0AL JO42OX 145.58750 144.98750 -0.6 DMR Langwedel DMR-ID: 2623208
DB0BS JO31OL 145.58750 144.98750 -0.6 DStar Bochum

Deutschlandreflektor

DCS001C voreingestellt
DB0LY JO63PF 145.58750 144.98750 -0.6 DStar Lychen
DB0NDS JO53KB 145.60000 145.00000 -0.6 C4FM Zernien FM/C4FM
DB0SH JO44RS 145.60000 145.00000 -0.6 FM Flensburg
DB0BHV JO43HO 145.60000 145.00000 -0.6 FM Bremerhaven Echolink 957085
DM0TMM JO52TD 145.60000 145.00000 -0.6 FM Magdeburg
DF0MHR JO31KK 145.60000 145.00000 -0.6 FM Mühlheim Ruhr

D-Star

DCS001S voreingestellt
DB0UH JO31SI 145.60000 145.00000 -0.6 FM Hagen
DB0XF JN58TM 145.60000 145.00000 -0.6 FM Sünzhausen
DM0KB-V JN47OP 145.60000 145.00000 -0.6 DMR Konstanz

Brandmeister

/FM 67.0 HZ CTCSS
DB0NHM JO51AQ 145.60000 145.00000 -0.6 FM Northeim

Tone: 1750 Hz DTMF,

Echolink Node #643561
DB0ZB JO50WB 145.60000 145.00000 -0.6 FM Schneeberg
DB0SP JO62NK 145.60000 145.00000 -0.6 FM Berlin-Wannsee
DB0SR JN39MI 145.60000 145.00000 -0.6 FM Heusweiler
DB0RUG JO64RK 145.60000 145.00000 -0.6 FM Bergen / Rügen
OZ3REG JO55ST 145.60000 145.00000 -0.6 FM Vejrhoj 1750 Analog
OZ7RER JO46EC 145.60000 145.00000 -0.6 FM Vestjylland 77 77 Analog
DB0FT JO40FF 145.60000 145.00000 -0.6 FM

Gr. Feldberg im

Taunus

 Trägergesteuert
PI3TWE JO32GL 145.60000 145.00000 -0.6 FM Den Ham Twentse Niederlande CTCSS 77,0 Hz
DB0HHO-C JO53DP 145.61250 145.01250 -0.6 DStar Großhansdorf
OZ5REP JO56CC 145.61250 145.01250 -0.6 FM Aarhus FM 1750 77 PLANNED Analog
DB0STM JO42RK 145.61250 145.01250 -0.6 FM Klein Heidorn
DB0FFL JN68EO 145.61250 145.01250 -0.6 FM Bergham
DM0GAP JN57NM 145.61250 145.01250 -0.6 FM

Garmisch-

Partenkirchen

Wank

CTCSS: 123 Hz, FM

Echolink EL#771931
DB0RTV JO32QG 145.61250 145.01250 -0.6 FM Rheine Echolink Node: #501950
OZ2RES JO66GA 145.61250 145.01250 -0.6 C4FM HELSINGOR Fusion
DB0MG JO31EE 145.61250 145.01250 -0.6 FM Mönchengladbach

Nur NFM nutzen,

Relais ist USV-versorgt,

Sendeseitig Subaudio 94,8 Hz
DB0YB JO40VU 145.61250 145.01250 -0.6 FM Bad Hersfeld
OZ6RED JO47XL 145.61250 145.01250 -0.6 FM Hjorrring 94.8 Analog
OZ9REV JO45LC 145.61250 145.01250 -0.6 FM Vongshoj 1750 Analog
DB0WV JN47QT 145.62500 145.02500 -0.6 FM

Höchsten

(Ilmensee)

 Echolink 301572
DB0ZA JO44UK 145.62500 145.02500 -0.6 FM Aschberg seit 3.9.17 wieder in Betrieb
DB0WB JN68DE 145.62500 145.02500 -0.6 FM Winterberg
DB0WU JO43JB 145.62500 145.02500 -0.6 FM Bremen
DB0XS JN39GM 145.62500 145.02500 -0.6 FM

Mettlach-

Orscholz


DB0UB JN59MU 145.62500 145.02500 -0.6 FM

Bamberg/

Kälberberg

 mit Tonruf öffnen
DB0ANA JO60MN 145.62500 145.02500 -0.6 FM

Poehlberg

Annaberg-

Buchholz


DB0ZH JN49IJ 145.62500 145.02500 -0.6 FM Heidelberg
DB0SA JO41KX 145.62500 145.02500 -0.6 FM Detmold 67 Hz Subcarrier
PI3AMF JO22QD 145.62500 145.02500 -0.6 FM

Amersfoort

Niederlande


DB0LOE JO71HA 145.62500 145.02500 -0.6 FM Kottmar
DB0MGG JO51IS 145.62500 145.02500 -0.6 FM

Drei Annen

Hohne

 Naehe Hohne Hof
DB0SP JO62NK 145.62500 145.02500 -0.6 C4FM Berlin-Wannsee
DB0NBB JO63PN 145.62500 145.02500 -0.6 FM Neubrandenburg
OZ3REE JO46NF 145.62500 145.02500 -0.6 FM Herning 1750 Analog
DB0YJ JO41XM 145.62500 145.02500 -0.6 FM Göttingen
OZ3REJ JO55WM 145.62500 145.02500 -0.6 FM Ringsted 1750 Analog
DB0IZ-C JO43RV 145.63750 145.03750 -0.6 DStar Krempermoor
DB0GKN JN49OE 145.63750 145.03750 -0.6 FM Heilbronn

Echolink: Node EL#469491

(zur Zeit offline)
DB0YC JN69JB 145.63750 145.03750 -0.6 FM Kreuzhaus CTCSS 71,9Hz
DB0UA JN58LI 145.63750 145.03750 -0.6 FM Augsburg CTCSS 88,5Hz, Echolink 14422
DB0BLK JN39QG 145.63750 145.03750 -0.6 C4FM Blieskastel
DB0DVR JO52FF 145.63750 145.03750 -0.6 FM Braunschweig
DB0YS JO40AX 145.63750 145.03750 -0.6 FM Kreuztal Echolink ID: 637002
DB0FUL JO40UO 145.63750 145.03750 -0.6 FM

Fulda-

Hummelskopf


OZ1REX JO46SE 145.63750 145.03750 -0.6 FM SILKEBORG -SQ- Analog
DB0FUE JN59LL 145.63750 145.03750 -0.6 FM Fürth
DM0HEI-C JO44PF 145.65000 145.05000 -0.6 DStar Schalkholz
DB0VP JN39TE 145.65000 145.05000 -0.6 C4FM Pirmasens CTCSS 77 Hz
DB0VP JN39TE 145.65000 145.05000 -0.6 FM Pirmasens CTCSS 77 Hz
OZ3REK JO45EM 145.65000 145.05000 -0.6 FM Esbjerg - VHF 1750 Analog
OZ4REN JO46VV 145.65000 145.05000 -0.6 FM Støvring 1750 Analog
DB0WE JO31LJ 145.65000 145.05000 -0.6 FM Essen

RX & TX CTCSS 67Hz,

Ausgabe fest FM, Eingabe

FM und C4FM möglich
DB0WOF JO61DQ 145.65000 145.05000 -0.6 FM Wolfen
DB0MVP JO53QP 145.65000 145.05000 -0.6 FM Schwerin C4FM Testbetrieb
DB0UP JN48IV 145.65000 145.05000 -0.6 FM

Wasserturm

Wartberg

Pforzheim

Eingabe mit CTCSS 94,8 Hz,

Ausgabe ohne CTCSS.
OZ3REF JO55EJ 145.65000 145.05000 -0.6 FM Odense (lokal) 1750 Analog
OZ3REP JO54RU 145.65000 145.05000 -0.6 FM Lolland 82.5 Analog
DB0HRM JO41WE 145.65000 145.05000 -0.6 FM Hoher Meißner HR-Turm
DB0UN JN59MK 145.65000 145.15000 -0.5 FM Nürnberg
DB0XH JO43VN 145.66250 145.06250 -0.6 FM HH-Blankenese CTCSS 79,7Hz
DB0ZL JN68AQ 145.66250 145.06250 -0.6 FM Rottenburg an der Laaber CTCSS 91,5Hz
DB0LSA JO61FH 145.66250 145.06250 -0.6 FM Leipzig
DB0EE JO31DU 145.66250 145.06250 -0.6 FM Emmerich
DB0VD JN49HR 145.66250 145.06250 -0.6 FM

Zwingenberg

Melikobus

 1750 Hz
OZ4GRE JO56KK 145.66250 145.06250 -0.6 FM Grenaa Analog
DB0ARB JN69NC 145.67500 145.07500 -0.6 FM Großer Arber CTCSS 71,9Hz
DB0XN JO44LP 145.67500 145.07500 -0.6 FM Bredstedt
DB0WZ JN49WS 145.67500 145.07500 -0.6 FM Würzburg CTCSS: 88,5Hz
DB0GSH JO51EV 145.67500 145.07500 -0.6 FM Steinberg
DB0PDM JO62MI 145.67500 145.07500 -0.6 FM Potsdam

Multimode /

Auftasten mit 1750Hz Rufton
DB0YH JN47CR 145.67500 145.07500 -0.6 FM Höchenschwand
DB0PDF JO42CW 145.67500 145.07500 -0.6 FM

Sage -

Grossenkneten

Rufton 1750 Hz

oder CTCSS 123 Hz
EL#715492
DB0ETB JO51PA 145.67500 145.07500 -0.6 FM

Weimar

Ettersberg


DB0SD JN39QR 145.67500 145.07500 -0.6 FM

Göttschied/

Flugplatz


DB0UK JN49EA 145.67500 145.07500 -0.6 FM Karlsruhe

CTCSS 94,8 Hz,

Notstrom
DB0VR JO31VD 145.67500 145.07500 -0.6 FM Nordhelle 67Hz CTCSS
DB0DD JO61VC 145.67500 145.07500 -0.6 FM Dresden-Hellerau

CTCSS 94.8 Hz,

Rutfon 1750
DB0GWD JO64QB 145.67500 145.07500 -0.6 FM Greifswald
DB0UK JN49EA 145.67500 145.07500 -0.6 C4FM Karlsruhe

CTCSS 94,8 Hz

für nur FM-Betrieb
OZ9REG JO45VX 145.67500 145.07500 -0.6 FM Yding Skovhøj 1750 77 Analog
DB0SBX JO60IT 145.68750 145.08750 -0.6 DStar Hohenstein
DM0IZH-C JO43SW 145.68750 145.08750 -0.6 DStar Itzehoe
OZ3REU-C JO65FP 145.68750 145.08750 -0.6 DStar HVIDOVRE D-Star
DB0TGM JO52XM 145.68750 145.08750 -0.6 C4FM Tangermünde CTCSS: 82.5Hz
DB0TGM JO52XM 145.68750 145.08750 -0.6 FM Tangermünde CTCSS: 82.5Hz
DB0BAC JN49SA 145.68750 145.08750 -0.6 FM

Großerlach

Hohenbrach

 ex DB0PE
DB0BAC JN49SA 145.68750 145.08750 -0.6 C4FM

Großerlach

Hohenbrach


DB0ZO JO42AE 145.68750 145.08675 -0.6 FM Döhrenberg CTCSS 123 Hz
DB0KUE JO54UD 145.68750 145.08750 -0.6 FM Kühlungsborn
PI3VNP JO32GL 145.68750 145.08750 -0.6 FM Den Ham Twentse Niederlande CTCSS 77,0 Hz
PI3VNP JO32GL 145.68750 145.08750 -0.6 C4FM Den Ham Twentse Niederlande CTCSS 77,0 Hz
DB0XK JN49AH 145.70000 145.10000 -0.6 FM Kalmit (Berg)  Maikammer
PI3EHV JO21RJ 145.70000 145.10000 -0.6 FM

Eindhoven

Niederlande

 CTCSS 71,9
DB0MAR JO54JA 145.70000 145.10000 -0.6 FM Timmendorf
DB0RH JO42WU 145.70000 145.10000 -0.6 FM Heiderelais
DB0WO JO33RF 145.70000 145.10000 -0.6 FM Leer
OZ9REB JO65FR 145.70000 145.10000 -0.6 FM Roret 82.5 Analog
OZ9REX JO46ES 145.70000 145.10000 -0.6 FM Hurup 94.8 94.8 Analog
OZ9REX JO46ES 145.70000 145.10000 -0.6 C4FM Hurup Fusion
DB0UC JO50LG 145.70000 145.10000 -0.6 FM Coburg Echolink: 96450
DB0SL JN68MV 145.70000 145.10000 -0.6 FM Greising Echolink 787694
DB0EB JO41WT 145.70000 145.10000 -0.6 FM Einbeck Eochlink #555416
DB0DON JN58JR 145.70000 145.10000 -0.6 FM Donauwörth
DB0HRR JO40RT 145.70000 145.10000 -0.6 DStar Breitenbach
DB0HS JO62OO 145.70000 145.10000 -0.6 C4FM 13503 Berlin - Heiligensee CTCSS 67 Hz auf dem FM-Träger
DB0SB JO30OP 145.70000 145.10000 -0.6 FM

Drachenfels

südlich

von Bonn


DB0SAX JO61MH 145.70000 145.10000 -0.6 FM Collmberg CTCSS: 67,0 Hz
DB0SAX JO61MH 145.70000 145.10000 -0.6 C4FM Collmberg CTCSS: 67,0 Hz
DB0WM JO31TX 145.70000 145.10000 -0.6 FM

St. Lamberti

Kirche (Münster)


OZ3REX JO55BJ 145.70000 145.10000 -0.6 FM Vissenbjerg 71.9 Analog
DO0ERK JO31ME 145.71250 145.11250 -0.6 DMR Haan Rheinland

Multimode DMR +

FM mit 67Hz
OZ0REC JO55WA 145.71250 145.11250 -0.6 C4FM Vordingborg PLANNED Fusion
OZ0REC JO55WA 145.71250 145.11250 -0.6 FM Vordingborg 82.5 82.5 PLANNED Analog
DB0ZW JN69AS 145.71250 145.11250 -0.6 FM Gramlhof

CTCSS 82,5Hz,

Echolink 362649
DB0SRS JO40RG 145.71250 145.11250 -0.6 FM

Bad Soden-

Salmünster

 CTCSS: 71,9 Hz Subaudio
DB0DOS JO42AE 145.71250 145.11250 -0.6 FM Bad Iburg CTCSS 123 Hz
DB0XR JN37XP 145.71250 145.11250 -0.6 FM

Hornberg -

Herrischried

 Echolink EL#205527
DB0YY JN48OV 145.71250 145.11250 -0.6 FM Ludwigsburg - Osterholzschule
DB0DOS JO42AE 145.71250 145.11250 -0.6 DMR Bad Iburg CSS 123 Hz
DB0XY JO51EU 145.72500 145.12500 -0.6 FM Bocksberg Goslar - Hahnenklee
PI3ZLB JO20VX 145.72500 145.12500 -0.6 FM

Geleen

Niederlande

 CTCSS 71,9
DB0ZK JO30SH 145.72500 145.12500 -0.6 FM

Kühkopf bei

Koblenz

Bei FM:

Subaudioton von 103,5 Hz
DB0ZU JN57LK 145.72500 145.12500 -0.6 FM Zugspitze Subton 88,5 Hz
DB0WZ-C JN49WS 145.72500 145.12500 -0.6 DStar Würzburg
OZ3RED JO56AL 145.72500 145.12500 -0.6 FM Randers 1750 Analog
OZ3REI JO45RD 145.72500 145.12500 -0.6 FM Knivsbjerg 1750 Analog
DB0SM JO32QR 145.72500 145.12500 -0.6 FM Meppen SVX-LINK Anbindung
DB0BRL JO62RM 145.72500 145.12500 -0.6 FM Berlin-Höhenschönhausen Trägersteuerung
DB0ZK JO30SH 145.72500 145.12500 -0.6 C4FM Kühkopf bei Koblenz
DB0ERZ JO60HK 145.72500 145.12500 -0.6 FM Eibenstock
OZ9REH JO66CB 145.72500 145.12500 -0.6 FM Ramlose 1750 82.5 Analog
DB0XN JO44LP 145.73750 145.13750 -0.6 DStar Bredstedt
DB0NN JO42PX 145.73750 145.13750 -0.6 FM

Holtum-

Geest bei Verden.

CTCSS 123,0 Hz
OZ9RES JO47HC 145.73750 145.13750 -0.6 FM Hanstholm 1750 94.8 94.8 Analog
DB0RDH JN68KW 145.73750 145.13750 -0.6 DStar Grandsberg
DB0YK JN39PJ 145.73750 145.13750 -0.6 FM Bexbach
DO0SMG JO64TN 145.73750 145.73750 0 FM

Sagard Hoch

Seelow

 Simplex
DB0LS JO61VM 145.73750 145.13750 -0.6 FM Kostebrau
DB0THA JO50JP 145.73750 145.13750 -0.6 FM Schneekopf
DB0DO JO31SL 145.73750 145.13750 -0.6 FM Schwerte

CTCSS 67Hz,

fest gekoppelt mit DB0TT
DB0LD JN49TH 145.73750 145.13750 -0.6 FM Künzelsau
OZ5REJ JO45NQ 145.73750 145.13750 -0.6 FM Skjoldbjerg 77 PLANNED Analog
OZ7REP JO55QR 145.73750 145.13750 -0.6 FM Snertinge 82.5 Analog
OZ9REU JO55LR 145.73750 145.13750 -0.6 FM Kalundborg 1750 Analog
DB0TK JN69BA 145.75000 145.15000 -0.6 FM Regensburg

CTCSS 100Hz,

Nur zum Empfang.

Nicht mit CTCSS senden,

da es sonst

zu Störungen kommt
DM0MAX JO42IG 145.75000 145.15000 -0.6 FM Wiehengebirge

CTCSS TX 88,5 RX

oder 1750Hz

SQL offen min 3sec
OZ7REF JO55GC 145.75000 145.15000 -0.6 FM Svendborg 1750 Analog
DK0TEN JN47NT 145.75000 145.15000 -0.6 FM

Sipplingen

/ Bodensee

 1750 Hz
DB0HTV JO40HD 145.75000 145.15000 -0.6 FM Frankfurt Main
DF0ANN JN59PL 145.75000 145.15000 -0.6 FM Moritzberg 77.0 Hz CTCSS
DB0ST JN48NR 145.75000 145.15000 -0.6 FM Stuttgart
DB0HAL JO51XO 145.75000 145.10000 -0.7 FM Petersberg / Saale
DB0XO JO30IW 145.75000 145.15000 -0.6 FM Bergheim (Glessener Höhe)
DB0ABB JO41UO 145.75000 145.15000 -0.6 FM Adelebsen
DB0HHH JO53CL 145.75000 145.15000 -0.6 FM HH-Lohbrügge CTCSS 79,7Hz,
EL#987869
OZ2REU JO65GP 145.75000 145.15000 -0.6 FM HCO 82.5 82.5 Analog
OZ4REX JO46MO 145.75000 145.15000 -0.6 FM Skive 1750 Analog
OZ4RED-C JO45FM 145.76250 145.16250 -0.6 DStar ESBJERG
DM0FL JO44ST 145.76250 145.16250 -0.6 FM Flensburg

Multimode C4FM

/ FM Subaudio mit

67Hz CTCSS TX
DM0FL JO44ST 145.76250 145.16250 -0.6 C4FM Flensburg

Multimode C4FM

/ FM Subaudio mit

67Hz CTCSS TX
DB0FTS JO50IO 145.76250 145.16250 -0.6 FM Suhl
OZ0REG JO65EQ 145.76250 145.16250 -0.6 FM GLOSTRUP ? 1750 Analog
OZ3REQ-C JO56CE 145.76250 145.16250 -0.6 DStar AARHUS D-Star PLANNED ircDDB
DB0HEI JO44NE 145.77500 145.17500 -0.6 FM Heide
DB0XX JO52MF 145.77500 145.17500 -0.6 FM Helmstedt
DB0LEI JO61EH 145.77500 145.17500 -0.6 FM Leipzig
DB0MAK JO60BA 145.77500 145.17500 -0.6 FM Marktredwitz, OT Haingrün

Rufton 1750Hz, CTCSS 74.4Hz,

Echolink 237686
DB0VQ JO32OH 145.77500 145.17500 -0.6 FM Bad Bentheim
DB0LHR JN38WI 145.77500 145.17500 -0.6 FM Lahr

APRS-Client,

Echolink,

HAMNET-Knoten,

Packet-Knoten
DB0XE JO41QH 145.77500 145.17500 -0.6 FM Kassel CTCSS 123Hz
DB0RIG JN48WQ 145.77500 145.17500 -0.6 FM Donzdorf
DB0HRO JO64AD 145.77500 145.17500 -0.6 FM Rostock Lütten Klein bei Rostock
DB0VK JO30LW 145.77500 145.17500 -0.6 FM Köln Rufton 1750 Hz
DB0UT JN39NR 145.77500 145.17500 -0.6 FM Kahlheid
DB0XW JO33UN 145.77500 145.17500 -0.6 FM Wittmund

1750 Hz Tonruf oder

71,9 Hz CTCSS
OZ3RET JO57GH 145.77500 145.17500 -0.6 FM Saeby 1750 Analog
OZ6REV JO55UW 145.77500 145.17500 -0.6 FM Nykobing S 1750 Analog
DB0WA JO30AR 145.78750 145.18750 -0.6 FM Aachen CTCSS 94,8Hz
DM0HMB-C JO53AN 145.78750 145.18750 -0.6 DStar HH-Mitte
OZ2REO-C JO65FR 145.78750 145.18750 -0.6 DStar MORKHOJ D-Star
DB0ELR JO32SU 145.78750 145.18750 -0.6 FM Sögel CTCSS 123 Hz
DB0WD JO42RG 145.78750 145.18750 -0.6 FM Deister
DB0HK JO40OM 145.78750 145.18750 -0.6 FM

Hoherodskopf -

Schotten


DB0AND JN59GH 145.78750 145.18750 -0.6 FM Ansbach Echolink # 933350 nicht aktiv
DB0TS JN69EM 145.78750 145.18750 -0.6 FM Am Eisenberg
DB0BRB JO62GJ 145.78750 145.18750 -0.6 FM

THB/

Brandenburg

an der Havel


OZ0RES JO46HL 145.78750 145.18750 -0.6 FM Struer 94.8 94.8 Yaesu Fusion Analog
OZ0RES JO46HL 145.78750 145.18750 -0.6 C4FM Struer Yaesu Fusion Fusion
PI2YSS JO32CD 430.01250 431.61250 1.6 FM

Zutphen

Niederlande

CTCSS 77,0 Hz

Repeater-Shift +1,6 MHz
PI2BOZ JO21DL 430.02500 431.62500 1.6 FM Bergen op Zoom Niederlande CTCSS 88,5 Hz
PI2ASN JO32GX 430.05000 431.65000 1.6 FM

Assen

Niederlande

CTCSS 82,5

Repeater-Shift: +1,6 Mhz
PI2ANH JO21WW 430.05000 431.65000 1.6 FM Arnheim Oosterbeek Niederlande

CTCSS: 77.0

Repeater-Shiift: + 1,6 MHz
DB0MOT JO40FF 430.07500 430.07500 0 TETRA

Feldberg /

Taunus


DB0MOT JO40FF 430.07500 430.07500 0 TETRA

Feldberg /

Taunus


DB0EDF JO31FC 430.07500 430.07500 0 TETRA

Jüchen -

Hochneukirch


DB0SRE JO31OO 430.07500 430.07500 0 TETRA Recklinghausen

abgeschaltet wegen

Nichtnutzung bzw.

zu geringer Reichweite
PI2EHV JO21QK 430.10000 431.70000 1.6 FM

Eindhoven

Niederlande

CTCS 71,9 Hz

(Shift +1,6 MHz)
PI2NOS JO20WX 430.12500 431.72500 1.6 FM

Hilversum

Niederlande


PI2TWE JO32GL 430.22500 431.82500 1.6 FM Den Ham Twentse Niederlande Shift +1.6 Mhz
PI2AMF JO22QD 430.25000 431.85000 1.6 FM

Amersfoort

Niederlande


PI2NON   430.2750 431.87500 1.6 FM GR, FR, DR, OV  CoVersity 21 relaisstations
PI2BRD JO21JO 430.32500 431.92500 1.6 DMR

Breda

Niederlande

 DMR-ID: 204510 Brandmeister
DB0MUE JO31KK 430.35000 430.35000 0 TETRA Mühlheim / Ruhr Echolink DB0MUE-R EL#856593
DM0NOR JO33OR 430.37500 430.37500 0 DStar Norderney simplex
DM0SVX JO51XL 430.37500 430.37500 0 TETRA Halle / Saale Echolink Node: #890492
DB0ST JN48NR 430.37500 430.37500 0 TETRA Stuttgart
DB0TST JN48NQ 430.37500 430.37500 0 TETRA

Leinfelden-

Musberg


DB0AVR JO30CS 430.37500 430.37500 0 TETRA Stolberg
DB0FEU JN59DD 430.37500 430.37500 0 TETRA Feuchtwangen
DB0DMO JO31ID 430.37500 430.37500 0 TETRA Neuss
PI2ALK JO22IP 430.37500 431.97500 1.6 FM

Alkmaar

Niederlande

CTCSS: 88,5 Hz

Repeater-Shift: +1,6 MHz
DB0TT JO31SL 430.37500 430.37500 0 TETRA Schwerte TETRA DMO
DM0HAT JO54LD 430.38750 430.38750 0 DMR Grömitz
DB0RKS JN68IE 431.90000 439.50000 7.6 FM Burgkirchen

Relaiskoppelsystem,

Ablage: +7.6 MHz
DO0XX JN49DL 432.67000 144.67000 -288 C4FM 67071 Ruchheim Mulitmodetransponder, FDMA
DB0USL JO41TQ 432.82500 432.82500 0 FM Uslar

Simplex-Echolink-Node

und Ortswelle H34 Uslar
DB0HAA JO31SI 432.85000 432.85000 0 FM Hagen Echolink: EL #42642
DB0FTC JN49BO 432.85000 432.85000 0 FM Quirnheim Solarpark

simplex,

Echolink EL#512503
OZ9AFZ-B JO75LD 433.43750 433.43750 0 DStar OSTERLARS HS HotSpot D-Star
OZ6DST-B JO57GI 434.45000 434.45000 0 DStar SAEBY HOTSPOT Open HS HotSpot D-Star
OZ7DSD-B JO45VX 434.45000 434.45000 0 DStar BROKBJERG Open HS HotSpot D-Star
OZ9DSD-B JO56FL 434.45000 434.45000 0 DStar VIVILD HOTSPOT Open HS HotSpot D-Star
OZ7DST-B JO47VL 434.47500 434.47500 0 DStar LØNSTRUP HS HotSpot D-Star
OZ0EVA-B JO57GR 434.48750 434.48750 0 DStar SKAGEN HOTSPOT SE INFO HotSpot D-Star
OZ0RED-B JO54SS 434.51250 432.51250 -2 DStar MARIBO D-Star
OZ7RES-B JO45FM 434.51250 432.51250 -2 DStar ESB TEST 7RES TESTING D-Star
OZ0REA-B JO55VF 434.52500 432.52500 -2 DStar NAESTVED SE INFO D-Star
OZ1REF-B JO45VN 434.52500 432.52500 -2 DStar FREDERICIA D-Star
OZ4REN-B JO46VV 434.52500 432.52500 -2 DStar STOEVRING D-Star
OZ7RET-B JO45NA 434.52500 432.52500 -2 DStar

Ravstedt

Danmark

 D-Star
OZ7RET-B JO45NA 434.52500 432.52500 -2 FM

Ravstedt

Danmark


OZ7RET-B JO45NA 434.52500 432.52500 -2 DStar

Ravstedt

Danmark


OZ0REH-B JO75JE 434.53750 432.53750 -2 DStar KLEMENSKER D-Star
OZ1REH-B JO46LC 434.53750 432.53750 -2 DStar HERNING D-Star
OZ2REE-B JO55GI 434.53750 432.53750 -2 DStar

Odense Fyn

Danmark

 D-Star
OZ3REQ-B JO56CE 434.53750 432.53750 -2 DStar AARHUS D-Star
OZ7REL-B JO46PW 434.53750 432.53750 -2 DStar L0GST0R D-Star
OZ2REE-B JO55GI 434.53750 432.53750 -2 FM

Odense Fyn

Danmark


OZ2REE-B JO55GI 434.53750 432.53750 -2 DStar

Odense Fyn

Danmark


OZ2REE-B JO55GI 434.53750 432.53750 -2 DMR

Odense Fyn

Danmark

 DMR-Plus ID: 238301
OZ2REX-B JO65BT 434.53750 432.53750 -2 DStar FREDERIKSUND D-Star
OZ1REC-B JO57AC 434.55000 432.55000 -2 DStar VODSKOV D-Star
OZ2REM-B JO65GQ 434.55000 432.55000 -2 DStar DOMUS KBH F D-Star
OZ4RED-B JO45FM 434.55000 432.55000 -2 DStar ESBJERG
OZ5DS-B JO55JI 434.55000 432.55000 -2 DStar NYBORG D-Star
OZ9RET-B JO46ES 434.55000 432.55000 -2 DStar HURUP THY D-Star
OZ0REV-B JO55BJ 434.56250 432.56250 -2 DStar VISSENBJERG D-Star
OZ1REJ-B JO47XL 434.56250 432.56250 -2 DStar HJØRRING D-Star
OZ1RES-B JO45GX 434.56250 432.56250 -2 DStar SKJERN D-Star
OZ2RET-B JO66GA 434.56250 432.56250 -2 DStar HELSING0R D-Star
OZ9REZ-B JO56AL 434.56250 432.56250 -2 DStar RANDERS D-Star
OZ0DST-B JO57FL 434.57500 432.57500 -2 DStar FREDERIKSHAVN D-Star
OZ0REF-B JO55QJ 434.57500 432.57500 -2 DStar SLOTS BJERGBY D-Star
OZ0yxz-B JO46TX 434.57500 432.57500 -2 DStar NIBE PLANNED D-Star
OZ1REO-B JO65FR 434.57500 432.57500 -2 DStar M0RKH0J D-Star
OZ2REG-B JO45TM 434.57500 432.57500 -2 DStar TREKANTEN D-Star
OZ2REL-B JO56CB 434.57500 432.57500 -2 DStar AARHUS S D-Star
OZ0REC-B JO55WA 434.58750 432.58750 -2 DStar VORDINGBORG D-Star
OZ1REI-B JO55GC 434.58750 432.58750 -2 DStar SVENDBORG D-Star
OZ2DST-B JO47XG 434.58750 432.58750 -2 DStar BR0NDERSLEV D-Star
OZ2REC-B JO46RP 434.58750 432.58750 -2 DStar AALESTRUP PLANNED D-Star
OZ3REU-B JO65FP 434.58750 432.58750 -2 DStar HVIDOVRE Temp QRT D-Star
OZ0MOG JO55WD 434.60000 432.60000 -2 FM Mogenstrup 82.5 MixMode Analog
OZ0MOG JO55WD 434.60000 432.60000 -2 DMR Mogenstrup cc15 MixMode DMRplus
OZ0MOG-B JO55WD 434.60000 432.60000 -2 DStar Mogenstrup MixMode D-Star
OZ2RES-B JO65DW 434.60000 432.60000 -2 DStar HILLER0D Temp QRT D-Star
OZ3DST-B JO47WA 434.60000 432.60000 -2 DStar AALBORG CITY D-Star
OZ3REY-B JO45RD 434.60000 432.60000 -2 DStar Knivsbjerg D-Star
OZ0REV JO55BJ 434.61250 432.61250 -2 DMR Vissenbjerg cc13 DMRplus
OZ1VIB JO46QL 434.61250 432.61250 -2 DMR Viborg cc12 DMRplus
OZ4KAR JO55TV 434.61250 432.61250 -2 DMR Vig cc15 DMRplus
OZ9REF JO64AV 434.61250 432.61250 -2 DMR Stubbekøbing cc15 BrandM
OZ0KAR JO65FR 434.62500 432.62500 -2 DMR Herlev cc14 BrandM
OZ4REF JO55QJ 434.62500 432.62500 -2 DMR Slagelse cc15 BrandM
OZ8EVA JO57FK 434.62500 432.62500 -2 DMR Frederikshavn cc11 DMRplus
OZ0REE JO56II 434.62500 432.62500 -2 DMR Grenaa cc12 SE INFO DMRplus
OZ6DMR JO66GA 434.63750 432.63750 -2 FM Helsingør mix

-NO- 82.5 82.5 DMR+

FM Analog
OZ0REN JO54WS 434.63750 432.63750 -2 FM Nykøbing F mix 82.5 82.5 PLANNED Analog
OZ0REN JO54WS 434.63750 432.63750 -2 DMR Nykøbing F mix cc15 PLANNED DMRplus
OZ3REQ JO56CE 434.63750 432.63750 -2 DMR Aarhus cc12 DMRplus
OZ4REG JO65AL 434.63750 432.63750 -2 DMR Regnemark cc9 BrandM
OZ6DMR JO66GA 434.63750 432.63750 -2 DMR Helsingør mix

cc14 DMR+

FM BrandM
OZ6REC JO55TP 434.65000 432.65000 -2 DMR Regstrup cc9 PLANNED DMRplus
OZ6REY JO45FM 434.65000 432.65000 -2 DMR Esbjerg N cc13, DMRplus
OZ8REK JO54RU 434.65000 432.65000 -2 FM Bandholm mix

-NO- 82.5 82.5 DMR+

FM Analog
OZ8REK JO54RU 434.65000 432.65000 -2 DMR Bandholm mix cc15 DMR+ FM DMRplus
OZ2KAR JO65BP 434.66250 432.66250 -2 DMR Roskilde cc15 BrandM
OZ9CH JO45QI 434.66250 432.66250 -2 DMR Christiansfeld cc13 PLANNED DMRplus
OZ1REC JO57AC 434.67500 432.67500 -2 DMR Vodskov cc11 DMRplus
OZ2REM JO65GQ 434.67500 432.67500 -2 DMR DOMUS cc14 DMRplus
OZ6REQ JO45VX 434.67500 432.67500 -2 DMR Yding cc12 DMRplus
OZ0AMG JO65HP 434.68750 432.68750 -2 DMR Amager cc14 BrandM
OZ0REA JO55VF 434.68750 432.68750 -2 DMR NAESTVED cc15 DMRplus
OZ4REN JO46VV 434.68750 432.68750 -2 DMR Støvring cc11 DMRplus
OZ8HYT JO65GX 434.68750 432.68750 -2 DMR Humlebæk cc9 BrandM
OZ8REC JO45EM 434.68750 432.68750 -2 DMR Guldager cc13 TESTING DMRplus
OZ1REL JO46GP 434.70000 432.70000 -2 FM Thyholm mix

94.8 94.8 DMR+

FM Analog
OZ1REL JO46GP 434.70000 432.70000 -2 DMR Thyholm mix

cc12 94.8 DMR+

FM DMRplus
OZ2REE JO55GI 434.70000 432.70000 -2 DMR Odense cc13 DMRplus
OZ0REB JO55UF 434.70000 432.70000 -2 DMR Næstved (2)

cc15 TESTING

DMRplus
OZ0REC JO55WA 434.70000 432.70000 -2 FM Vordingborg 82.5 82.5 Analog
OZ0REC JO55WA 434.70000 432.70000 -2 DMR Vordingborg cc15 DMRplus
OZ3KAR JO65CU 434.70000 432.70000 -2 DMR Gørløse cc14 BrandM
OZ8KAR JO55PQ 434.70000 432.70000 -2 DMR Snertinge cc9 DMRplus
OZ15DMR JO55PQ 434.71250 432.71250 -2 DMR Bregninge cc5 MotoTrbo
OZ20REQ JO65FR 434.71250 432.71250 -2 DMR Cph GLX cc4 MotoTrbo
OZ25REQ JO54RU 434.71250 432.71250 -2 DMR Bandholm cc5 MotoTrbo
OZ7KAR JO55TV 434.72500 432.72500 -2 DMR Højby Sj cc5 MotoTrbo
OZ0DMR JO55VN 434.73750 432.73750 -2 DMR Ebberup Sj cc5 MotoTrbo
DM0FL JO44ST 434.73750 434.73750 0 TETRA Flensburg

TETRA DMO,

POCSAG im

DAPNET auf 439,9875
OZ22REQ JO55QJ 434.75000 432.75000 -2 DMR Slagelse cc5 MotoTrbo
OZ7DMR JO66AB 434.75000 432.75000 -2 DMR Vejby cc4 MotoTrbo
OZ23REQ JO55DJ 434.76250 432.76250 -2 DMR Odense V cc3 MotoTrbo
OZ8DMR JO65FT 434.76250 432.76250 -2 DMR Holte cc4 MotoTrbo
OZ3DMR JO55UV 434.76250 432.76250 -2 DMR ASMINDRUP cc5 LOKAL MotoTrbo
OZ24REQ JO56CE 434.77500 432.77500 -2 DMR Risskov cc2 MotoTrbo
OZ6REH JO55GC 434.77500 432.77500 -2 DMR Svendborg cc3 MotoTrbo
DM0SL JO44SM 434.78750 434.78750 0 TETRA Schleswig
DB0XN JO44LP 434.78750 434.78750 0 TETRA Bredstedt
DM0UHF JN48TW 434.78750 434.78750 0 TETRA Erkelenz
DB0HKN JN57UV 434.78750 434.78750 0 TETRA Holzkirchen
DB0KPG JO30NU 434.78750 434.78750 0 TETRA Köln
OZ12DMR JO45QU 434.78750 432.78750 -2 DMR Torphøj cc3 MotoTrbo
OZ21REQ JO65HQ 434.78750 432.78750 -2 DMR Cph City cc4 MotoTrbo
DB0FS JO43XO 434.78750 434.78750 0 TETRA HH-Lokstedt MCC: 901, MNC: 16383, TG1
OZ14DMR JO66GA 434.80000 432.80000 -2 DMR Helsingor cc4 MotoTrbo
OZ17DMR JO45TM 434.80000 432.80000 -2 DMR Fredericia cc3 Test QTH MotoTrbo
OZ2REN JO55XF 434.80000 432.80000 -2 DMR Raadegaard cc5 MotoTrbo
OZ1KARA JO65BP 434.81250 432.81250 -2 FM Roskilde 82.5 82.5 Analog
OZ5REQ JO54RS 434.82500 432.82500 -2 FM Maribo 1750 Analog
OZ9RER JO57GK 434.82500 432.82500 -2 FM Frederikshavn -NO- 94.8 Analog
OZ3REY JO45RD 434.82500 432.82500 -2 FM Knivsbjerg 1750 Analog
OZ5REZ JO46XB 434.82500 432.82500 -2 FM Skanderborg 1750 77 Analog
OZ9REH JO66BB 434.82500 432.82500 -2 FM Ramlose 1750 82.5 Ant SV Analog
OZ9REW JO46FQ 434.82500 432.82500 -2 FM Boddum -NO- 94.8 94.8 A.S.R.
OZ7RED JO46ES 434.83750 432.83750 -2 FM Hurup -NO- 94.8 94.8 A.S.R.
OZ9REB JO65FR 434.83750 432.83750 -2 FM Roret 82.5 82.5 Analog
OZ5REU JO55EJ 434.85000 432.85000 -2 FM Knæhoj Odense 1750 Analog
OZ8REH JO45LC 434.85000 432.85000 -2 FM Vongshoj 1750 TempQRT Analog
OZ0ASR JO46JH 434.85000 432.85000 -2 FM Holstebro 77 77 A.S.R.
OZ0KEC JO66DD 434.85000 432.85000 -2 FM Gilleleje -NO- 82.5 Analog
OZ0REI JO65AF 434.85000 432.85000 -2 FM Hyllede -110.9 110.9 A.S.R.
OZ2RED JO45TQ 434.86250 432.86250 -2 FM Andkær 77 A.S.R.
OZ2xyz JO46HW 434.86250 432.86250 -2 FM Thisted 94.8 PLANNED A.S.R.
OZ3REJ JO55WM 434.86250 432.86250 -2 FM Ringsted -NO- 82.5 Analog
OZ5REW JO46MO 434.87500 432.87500 -2 FM Skive 1750 Analog
OZ7REU JO65GP 434.87500 432.87500 -2 FM HCO 82.5 82.5 Analog
OZ9ARHU JO56DG 434.87500 432.87500 -2 FM Aarhus 77 77 Analog
OZ6REH JO55GC 434.87500 432.87500 -2 FM Svendborg 1750 71.9 Analog
OZ0REP JO46FD 434.88750 432.88750 -2 FM Spjald Analog
OZ6RET JO55PJ 434.88750 432.88750 -2 FM Slagelse -110.9 110.9 A.S.R.
OZ9HDR JO45RF 434.88750 432.88750 -2 FM Haderslev 88.5 Analog
OZ7GRE JO56KK 434.90000 432.90000 -2 FM Grenaa 1750 77 Analog
OZ0REQ JO45UM 434.90000 432.90000 -2 FM Fredericia Analog
OZ0RV JO46EW 434.90000 432.90000 -2 FM Stenbjerg 94.8 A.S.R.
OZ8REB JO55JH 434.90000 432.90000 -2 FM Nyborg 1750 Analog
OZ8REL JO65FR 434.90000 432.90000 -2 FM Gladsaxe 1750 82.5 Analog
OZ6REC JO55TP 434.91250 432.91250 -2 FM Regstrup 82.5 82.5 Analog
OZ5REO JO45SQ 434.92500 432.92500 -2 FM Vejle by 77 A.S.R.
OZ6REJ JO46VS 434.92500 432.92500 -2 FM Rold 1750 Analog
OZ9REI JO55ST 434.92500 432.92500 -2 FM Dutterhoj -110.9 110.9 A.S.R.
OZ0QA JO65EU 434.93750 432.93750 -2 FM Birkerød 110.9 A.S.R.
OZ0RES JO46HL 434.93750 432.93750 -2 FM STRUER 94.8 A.S.R.
OZ7RET JO45NA 434.95000 432.95000 -2 FM RAVSTED 1750 Analog
OZ9ASR JO55UK 434.95000 432.95000 -2 FM RINGSTED -110.9 110.9 A.S.R.
OZ9REP JO47WB 434.96250 432.96250 -2 FM Aalborg City 1750 94.8 Analog
OZ0GUT JO46DS 434.96250 432.96250 -2 FM Agger 94.8 A.S.R.
OZ4REY JO55LR 434.96250 432.96250 -2 FM Kalundborg 82.5 A.S.R.
OZ7ASR JO66FA 434.96250 432.96250 -2 FM Tikøb 110.9 PLANNED A.S.R.
OZ9REL JO45EM 434.96250 432.96250 -2 FM Esbjerg 88.5 88.5 A.S.R.
OZ2REX JO65BT 434.97500 432.97500 -2 FM Frederikssund SQ Analog
OZ5REB JO45VX 434.97500 432.97500 -2 FM Yding Skovhoj 1750 77 TempQRT Analog
OZ8REG JO55WA 434.98750 432.98750 -2 FM Vordingborg 82.5 82.5 Analog
OZ8ASR JO65HO 434.98750 432.98750 -2 FM Tårnby -110.9 110.9 A.S.R.
OZ9REZ JO56AL 434.98750 432.98750 -2 FM Randers 77 77 Analog
OZ9RLM JO46DN 434.98750 432.98750 -2 FM Lemvig 77 A.S.R.
DB0BC JO62PM 436.00000 1252.00000 816 ATV

Berlin-

Charlottenburg


PI1DRA JO33BC 438.00000 430.40000 -7.6 DMR

Drachten

Niederlande

DMR-ID: 204801

Brandmeister
PI1WFR JO22KQ 438.01250 430.41250 -7.6 DMR

Obdam

Niederlande

DMR-ID: 204103

Brandmeister
PI1AMS JO22JI 438.05000 430.45000 -7.6 DMR

Amsterdam

Niederlande

DMR-ID: 204101

Brandmeister
PI1UTR JO22MA 438.07500 430.47500 -7.6 DStar Ijsselstein
PI1HWB-B JO21JN 438.10000 430.50000 -7.6 DStar

Breda

Niederlande


PI1HWB JO21JN 438.10000 430.50000 -7.6 DStar

Breda

Niederlande


PI1VBG JO22EB 438.10000 430.50000 -7.6 FM

Den Haag

Voorburg

Niederlande

 CTCSS: 88,5 Hz
PI1VBG JO22EB 438.10000 430.50000 -7.6 C4FM

Den Haag

Voorburg

Niederlande

CTCSS: 88,5 Hz,

Repeater user ID: 31598
PI1MEP JO32CO 438.12500 430.52500 -7.6 DStar

Zwolle

Niederlande


DO0DMR JO31KI 438.12500 438.12500 0 DMR Ratingen
PI1ZLB JO20TU 438.15000 430.55000 -7.6 DMR

Limburg

Nederland

 DMR-ID: 204402
PI1KPH JO32CN 438.15000 430.55000 -7.6 DMR

Zwolle

Niederlande

DMR-ID: 204778

Brandmeister
PI1NOG JO33KH 438.15000 430.55000 -7.6 DMR

Delfzijl

Appingedam Niederlande

 DMR-ID:
DB0VA JO40BC 438.18750 430.58750 -7.6 DMR Taunusstein
DB0DY JO32WE 438.20000 430.60000 -7.6 DMR Lengerich
DF0MOT JO40FF 438.20000 430.60000 -7.6 DMR

Gr. Feldberg im

Taunus

 DMR-ID: 262600
DO0DMR JO31KI 438.20000 430.60000 -7.6 DMR Ratingen DMR ID: 262473
PI1DHG JO22EB 438.20000 430.60000 -7.6 DMR

Den Haag

Niederlande


DB0PBS JO41JR 438.21250 430.61250 -7.6 DMR Paderborn

Multimode DMR (default) /

C4FM
DO0OLG JO43CE 438.22500 430.62500 -7.6 C4FM Oldenburg

DO0OLG

wird ausschließlich als C4FM Relais mit WIRES-X Anbindung zum

NORD-OSTSEE-LINK betrieben
DO0OLG JO43CE 438.22500 430.62500 -7.6 C4FM Oldenburg Wires-X-Node ID:18683
PI1AMS JO22JI 438.22500 430.62500 -7.6 C4FM

Amsterdam

Niederlande

Wires-X ID: 27343,

CTCSS: 88,5 Hz
DB0MOT JO40FF 438.23750 430.63750 -7.6 DMR

Feldberg /

Taunus


DB0BAY JN69AH 438.25000 430.65000 -7.6 DMR

Scheckenberg

(bei Schwandorf)


DB0FS JO43XO 438.25000 430.65000 -7.6 C4FM HH-Lokstedt

Wire-X-ID 31703 Verbund:

DM0SL-Raum 27655 DM0SL (Schleswig), DB0XN

(Bredstedt),

DM0FL (Flensburg)

und DB0HEI (Heide)
PI1HGL-B JO22EC 438.25000 430.65000 -7.6 DStar

Den Haag

Niederlande


DB0KLL JO30GM 438.25000 430.65000 -7.6 C4FM Kall Eifel EL #379739
DB0KRM JO33NK 438.25000 430.65000 -7.6 C4FM

Krummhörn/

Pewsum

 12,5 KHz
DB0IUZ JO31OK 438.25000 430.65000 -7.6 DMR

Bochum-

Sternwarte


DB0FTC JN49BO 438.25000 430.65000 -7.6 DMR

Quirnheim

Solarpark

 simplex
PI1HRL JO20XW 438.26250 430.66250 -7.6 DMR

Heerlen /

Nederland

DMR-ID 204400

Brandmeister
PI1DHR JO22JW 438.26250 430.66250 -7.6 DStar

Den Helder

Niederlande


DB0HE JO31NO 438.26250 430.66250 -7.6 DStar Herten
DB0HE JO31NO 438.26250 430.66250 -7.6 DMR Herten

Multimode DMR /

DStar. DMR-ID: 262434
DB0OCH JN59BQ 438.26250 430.66250 -7.6 DMR

Frickenhausen

am Main

 DMR-ID BM 262806
DB0CHV JO43IU 438.27500 430.67500 -7.6 DMR

Cuxhaven,

Am alten Hafen 2


DM0MAX JO42IG 438.27500 430.67500 -7.6 C4FM Wiehengebirge

Yaesu Wires-X

(Node ID 18707 /

Room ID 28707)
PI1TWE JO32JG 438.27500 430.67500 -7.6 DMR

Hengelo

Niederlande

DMR-ID: 204711

Brandmeister
DB0VEL JO31MI 438.28750 430.68750 -7.6 DMR Velbert DMR-ID: 262463
DB0WO JO33RF 438.30000 430.70000 -7.6 DMR Leer
DB0IR-B JO44QR 438.30000 430.70000 -7.6 DStar Handewitt
DB0HKN JN57UV 438.30000 430.70000 -7.6 DMR Holzkirchen DMR-ID: 26285
DB0MYK JO30OJ 438.30000 430.70000 -7.6 DMR Gänsehals Eifel
DB0HGW JO64QC 438.30000 430.70000 -7.6 DMR Greifswald

DMR-Gateway |

BM access with 9 e.g. 9262
DB0MDX JO40JT 438.30000 430.70000 -7.6 FM Marburg Lahn 100Hz Subton
DB0MDX JO40JT 438.30000 430.70000 -7.6 C4FM Marburg Lahn
DB0HGW JO64QC 438.30000 430.70000 -7.6 C4FM Greifswald
DB0HGW JO64QC 438.30000 430.70000 -7.6 FM Greifswald
DB0VEL JO31MI 438.31250 430.71250 -7.6 DMR Velbert
PI1SHA JO22PJ 438.31250 430.71250 -7.6 DStar

Almere

Niederlande


DM0RAM-B JO53AI 438.31250 430.71250 -7.6 DStar Ramelsloh
PI1GRL JO32HA 438.32500 430.72500 -7.6 DMR

Groenlo

Niederland

 DMR-ID: 204666
DB0PAS JN68SO 438.32500 430.72500 -7.6 C4FM Passau-Thrynau

nur C4FM,

Echolink: Node # 438325
PI1SNK JO23TA 438.32500 430.72500 -7.6 DStar

Sneek

Niederlande


DO0DXE JO41RH 438.32500 430.72500 -7.6 DMR Kassel Node #262666
DB0DMB-B JO54CJ 438.32500 430.72500 -7.6 DStar Laboe
DB0HRH-B JN47EO 438.32500 430.72500 -7.6 DStar Küssaburg
DB0HER JN48JN 438.32500 430.72500 -7.6 DMR Herrenberg - Oberjettingen Wasserturm Brandmeister
DB0VA JO40BC 438.32500 430.72500 -7.6 DStar Taunusstein
DB0DMB-B JO54CJ 438.32500 430.72500 -7.6 DMR Laboe

DMR-ID: 262281,

auch D-Star und C4FM,

MMDVM Repeater

im Brandmeister Netz
DB0OZ JO43JC 438.32500 430.72500 -7.6 DMR Bremen
DB0LBG JN48PS 438.33750 430.73750 -7.6 DMR Esslingen-Katharinenlinde DMR+
DB0HEI JO44NE 438.33750 430.73750 -7.6 DMR Heide
PI1UTR JO22MA 438.35000 430.75000 -7.6 DMR Ijsselstein

DMR-ID: 204300

Brandmeister
DB0INS JO50FU 438.35000 430.75000 -7.6 DStar

Grosser

Inselberg


DM0SL-B JO44SM 438.35000 430.75000 -7.6 DStar Schleswig
DB0SHG JO42QE 438.35000 430.75000 -7.6 FM Süntelturm
DB0HD JN49IK 438.35000 430.75000 -7.6 C4FM Heidelberg Wires-X Node: 31487
DB0INS JO50FU 438.35000 430.75000 -7.6 C4FM

Grosser

Inselberg


DB0GIS JO40JN 438.35000 430.75000 -7.6 DStar

Fernwald-

Steinbach


DB0HAT JO31VQ 438.35000 430.75000 -7.6 DMR Hamm DMR Hytera,DCS4007 NRW
DB0INS JO50FU 438.35000 430.75000 -7.6 DMR

Grosser

Inselberg


DB0LT JO31KX 438.36250 430.76250 -7.6 DMR Stadtlohn
DB0DIL JO40BS 438.36250 430.76250 -7.6 DMR Haiger FM mit 123 Hz CTCSS
DB0DIL JO40BS 438.36250 430.76250 -7.6 FM Haiger FM mit 123 Hz CTCSS
PI1FRL JO23SC 438.36250 430.76250 -7.6 DMR

Burgwerd

Niederlande

DMR-ID: 204844

Brandmeister
PI1ADF JO22PJ 438.36250 430.76250 -7.6 DMR

Almere

Niederlande

DMR-ID: 204701

Brandmeister
DB0HHN JO53AS 438.37500 430.77500 -7.6 C4FM Götzberg FM/C4FM
DB0HHN JO53AS 438.37500 430.77500 -7.6 FM Götzberg 67.0 Hz
DO0JG JN58ME 438.37500 430.77500 -7.6 DMR Moorenweis MixedMode FM CTCSS 123,0
DO0SRE JO31OO 438.37500 430.77500 -7.6 DMR Recklinghausen qrv : Brandmeister DMR
DB0OL JO43CD 438.37500 430.77500 -7.6 DStar JO43CD
PI1DFT-1 JO21EX 438.37500 430.77500 -7.6 DMR

Delft

Niederlande

DMR-ID: 204204

Brandmeister
DB0SWR JN49RQ 438.37500 430.77500 -7.6 DStar Wertheim/Main

MMDVM-Multimode

D-Star + DMR

(DMRplus +

Brandmeister +

XLX)
DB0XN JO44LP 438.38750 438.38750 0 DStar Bredstedt
DB0AIS JN49HX 438.38750 430.78750 -7.6 FM

Moerfelden-

Walldorf

 Subton: 67,0 Hz
DB0AIS JN49HX 438.38750 430.78750 -7.6 C4FM

Moerfelden-

Walldorf

Subton: 67,0 Hz

C4FM-Wires-X Node: 31005
DB0PC JO54IF 438.38750 430.78750 -7.6 DMR Bungsberg

BrandMeister TG26222

(Ostholstein-Nord)
PI2APD JO22WF 438.38750 430.78750 -7.6 DMR

Apeldoorn

Niederlande

DMR-ID: 204600

Brandmeister
DB0DBN JO30OQ 438.38750 430.78750 -7.6 DMR

Königswinter

Oelberg

DMR-ID: 262461,

Brandmeister
PI1DSE-B JO21SK 438.40000 430.80000 -7.6 DStar

Eindhoven

Niederlande


DB0KX JO31EG 438.40000 430.80000 -7.6 C4FM Viersen

W-x#18601,

DM#262452
DB0EAT JO43VR 438.40000 430.80000 -7.6 DStar Ellerhoop
DB0DOS JO42AE 438.40000 430.80000 -7.6 FM Bad Iburg Multimode
DB0DOS JO42AE 438.40000 430.80000 -7.6 DStar Bad Iburg Multimode
DB0DOS JO42AE 438.40000 430.80000 -7.6 DMR Bad Iburg Multimode
DB0EAT JO43VR 438.40000 430.80000 -7.6 DMR Ellerhoop

DMR-ID 262280,

MMDVM

Repeater im Brandmeister Netz
DB0EAT JO43VR 438.40000 430.80000 -7.6 C4FM Ellerhoop
DB0LM JO40BI 438.40000 430.80000 -7.6 DMR

Mensfelden

Brechen

 DMR-ID: 262630
DB0BZA JN58TE 438.41250 430.81250 -7.6 FM München BSW

Echolink EL#711280,

Echolink derzeit im Betatest

GW zu YSF/DMR TG 26210 BM
DB0BZA JN58TE 438.41250 430.81250 -7.6 C4FM München BSW

Über WiresX DL BAYERN GW

zu YSF / DMR-BM-TG 26210 /

Echolink als GW in Planung
DM0HL JO53FV 438.41250 430.81250 -7.6 DMR

Poehls

bei Lübeck


DB0RES JO31ES 438.42500 430.82500 -7.6 DMR Rees
PI1UTR JO22MA 438.42500 438.42500 0 C4FM Ijsselstein CTCSS 77,0 Hz
PI1UTR JO22MA 438.42500 438.42500 0 FM Ijsselstein CTCSS 77,0 Hz
DB0LFH JO40JN 438.42500 430.82500 -7.6 C4FM

Fernwald,

Steinbach

(JO40JN)


DB0HUS JO44ML 438.42500 430.82500 -7.6 DMR Husum
DB0DRB JN39EX 438.42500 430.82500 -7.6 DStar

Hisel -

Bitburger-Land


DB0HUS JO44ML 438.42500 430.82500 -7.6 C4FM Husum
DB0RKD JO31JC 438.42500 430.82500 -7.6 DStar Dormagen FM/D-Star Mixmode
DB0CFM JO31HE 438.43750 430.83750 -7.6 C4FM Korschenbroich
DB0ACC JO31OR 438.45000 430.85000 -7.6 FM Haltern am See CTCSS: 67 Hz
DB0ACC JO31OR 438.45000 430.85000 -7.6 DMR Haltern am See DMR-ID: 262442
DM0HMB JO53AN 438.45000 430.85000 -7.6 DMR HH-Mitte
DB0WTV JO43BM 438.45000 430.85000 -7.6 C4FM Wilhelmshaven Linkverbund DL-NORDWEST
DM0KWD JO51XL 438.45000 430.85200 -7.6 DMR Halle / Saale DMR-ID: 262002
DB0ARD JN48XL 438.45000 430.85000 -7.6 DMR Dornstadt DMR ID: 262705
DB0NLH JO42DC 438.45000 430.85000 -7.6 C4FM Hollandskopf (bei Borgholzhausen)
DB0SYS JO31JC 438.46250 430.86250 -7.6 DMR Dormagen
DB0BRV JO43OI 438.46250 430.86250 -7.6 DMR Selsingen TG2622
DO0LL JO32NA 438.46250 430.86250 -7.6 DMR Legden
DB0BHV JO43HO 438.47500 430.87500 -7.6 DMR Bremerhaven DMR-ID: 262316
DB0SAA JN58BT 438.47500 433.87500 -4.6 DMR Oberkochen, Volkmarsberg Repeater ist im Motorola Netz eingebunden
DB0FHF JO44RS 438.47500 430.87500 -7.6 C4FM Flensburg
DB0USK JO54LI 438.47500 430.87500 -7.6 DStar Heiligenhafen
DB0YC JN69JB 438.47500 430.87500 -7.6 FM Kreuzhaus
DB0LDK JO40GM 438.47500 430.87500 -7.6 DMR Wetzlar Netz: DMR+
DB0NIS JO30EP 438.47500 430.87500 -7.6 FM

Nideggen /

Nordeifel


DB0WL JO53CI 438.48750 430.88750 -7.6 DMR Winsen/Luhe FM 67Hz;DMR-ID:262336
DB0WL JO53CI 438.48750 430.88750 -7.6 FM Winsen/Luhe FM 67 Hz
DB0MGN JO50FN 438.50000 430.90000 -7.6 DMR Meiningen

Mmdvm Multimode

Repeater dmr Dstar c4fm altiv
DO0DEL-B JO43HB 438.50000 430.90000 -7.6 DStar Delmenhorst
DB0AGM JO53GG 438.50000 430.90000 -7.6 DMR Lüneburg DMR-ID: 262337
DB0EIF JO30JG 438.50000 430.90000 -7.6 DMR

Dreis-Brück /

Eifel

 DMR ID Nr 262575
DB0TST JN48NQ 438.50000 430.90000 -7.6 DMR

Leinfelden-

Musberg


DB0WE JO31LJ 438.50000 430.90000 -7.6 C4FM Essen kein Mix Mode mit FM
DB0WE JO31LJ 438.50000 430.90000 -7.6 FM Essen C4FM
DB0EB JO41WT 438.51250 430.91250 -7.6 DMR Einbeck DMR-ID: 262345
DB0HAL JO51XO 438.51250 430.91250 -7.6 DMR

Petersberg /

Saale

 DMR-ID: 26204
DB0BNL JO43IE 438.51250 430.91250 -7.6 DMR Bremen Temporärer Standort
DB0RTV JO32QG 438.51250 430.91250 -7.6 DMR Rheine

MMDVM,

DMR-ID 262445,

TS1 BM262, TS2 BM2624 u. BM26242
DB0RTV JO32QG 438.51250 430.91250 -7.6 DStar Rheine MMDVM, NRW DCS001B
DB0RTV JO32QG 438.51250 430.91250 -7.6 C4FM Rheine MMDVM, DE-Germany #62829, TG26208
DB0HAL-D JO51XO 438.51250 430.91250 -7.6 DMR Halle Brandmeister DMR-ID: 262004
DB0PV JN58SC 438.52500 430.92500 -7.6 C4FM

München

Thalkirchen

per Hamnet in FCS001 angebunden,

Wires-X zur Zeit gestört
DB0PV JN58SC 438.52500 430.92500 -7.6 FM

München

Thalkirchen

FM-Repeater sendet (!) einen

77Hz CTCSS Ton aus.

So blenden die FM-Nutzer

das C4FM-Signal aus
DB0ST JN48NR 438.52500 430.92500 -7.6 DStar Stuttgart
DM0FL JO44ST 438.52500 430.92500 -7.6 FM Flensburg 67Hz CTCSS TX für FM
DM0FL JO44ST 438.52500 430.92500 -7.6 C4FM Flensburg Wires-X SH/HH
DB0HFD JO42ID 438.52500 430.92500 -7.6 DStar Herford
DB0KUA JO53EP 438.52500 430.92500 -7.6 DMR Lütjensee DMR-Plus ID 262260
DM0SL JO44SM 438.53750 430.93750 -7.6 DMR Schleswig
DB0ERB JN68CQ 438.53750 430.93750 -7.6 DMR Ergoldsbach DMR-ID: 262884
DB0CRA JN49XC 438.53750 430.93750 -7.6 DMR Crailsheim DMR-ID 262723
DB0FTS JO50IO 438.53750 430.93750 -7.6 DStar Suhl
DB0FTS JO50IO 438.53750 430.93750 -7.6 DMR Suhl
DB0FTS JO50IO 438.53750 430.93750 -7.6 C4FM Suhl
DB0EEE JN58DA 438.55000 430.95000 -7.6 DMR Erkheim Brandmeister
DB0EEE JN58DA 438.55000 430.95000 -7.6 DStar Erkheim MMDVM
DB0EEE JN58DA 438.55000 430.95000 -7.6 C4FM Erkheim MMDVM
DB0HEW JO53EJ 438.55000 430.95000 -7.6 DStar Geesthacht Multimode
DB0XN JO44LP 438.55000 430.95000 -7.6 C4FM Bredstedt
DB0WUR JO51HS 438.55000 430.95000 -7.6 FM Wurmberg
DM0VG JO63SS 438.55000 430.95000 -7.6 FM Spantekow
DB0TTM JN49VJ 438.55000 430.95000 -7.6 FM Bad Mergentheim-Herbsthausen
DB0GWG JO31OE 438.55000 430.95000 -7.6 FM Remscheid
DB0SOB JN58ON 438.55000 430.95000 -7.6 C4FM Schrobenhausen
DB0SOB JN58ON 438.55000 430.95000 -7.6 DStar Schrobenhausen
DB0SOB JN58ON 438.55000 430.95000 -7.6 DMR Schrobenhausen
DB0HEW JO53EJ 438.55000 430.95000 -7.6 FM Geesthacht

CTCSS Ausgabe 91,5 Hz,

Echolink 203651
DB0HEW JO53EJ 438.55000 430.95000 -7.6 DMR Geesthacht TS2 4002; TS1
DB0HEW JO53EJ 438.55000 430.95000 -7.6 C4FM Geesthacht
DB0LHR JN38WI 438.55000 430.95000 -7.6 DMR Lahr
DB0ZO JO42AE 438.55000 430.95000 -7.6 DStar Döhrenberg wg. Umbau nicht qrv
DM0HEI JO44PF 438.56250 430.96250 -7.6 DMR Schalkholz

D-Star, DMR( ID 262282),

C4FM, MMDVM

repeater im Brandmeister Netz
DM0HEI JO44PF 438.56250 430.96250 -7.6 C4FM Schalkholz

D-Star, DMR( ID 262282),

C4FM, MMDVM

repeater im Brandmeister Netz
DB0RI JO42NF 438.56250 430.96250 -7.6 FM Luhdener Klippe
DM0HEI JO44PF 438.56250 430.96250 -7.6 DStar Schalkholz

D-Star, DMR( ID 262282),

C4FM, MMDVM

repeater im Brandmeister Netz
DB0PDM JO62MI 438.56250 430.96250 -7.6 DMR Potsdam in Aufbau/Testbetrieb
DB0MGN JO50FN 438.56250 430.96250 -7.6 FM Meiningen Echolink Node #466108
DB0UT JN39NR 438.56250 430.96250 -7.6 FM Kahlheid
DB0YQ JN69CQ 438.56260 430.96250 -7.6 C4FM FMT Weiden
DB0LUD JO62PH 438.57500 430.97500 -7.6 FM Ludwigsfelde Mode : FM /C4FM
DB0RWP JN48HD 438.57500 430.97500 -7.6 FM Rottweil Echolink 72100
DB0BLA JO61IC 438.57500 430.97500 -7.6 FM

Bad Lausick

Geithain

 Echolink SVX-Linkserver in Planung
DB0AGM JO53GG 438.57500 430.97500 -7.6 FM Lüneburg

Multimode, Packet Radio,

RTTY, SSTV
DB0HCC-B JO43MT 438.57500 430.97500 -7.6 DStar Neuhaus
DB0WO JO33RF 438.57500 430.97500 -7.6 FM Leer Multimode
DB0DVR JO52FF 438.57500 430.97500 -7.6 DMR Braunschweig DMR+ ID: 262399
DB0BLK JN39QG 438.57500 430.97500 -7.6 FM Blieskastel

Multimode C4FM /

DMR, CTCSS 71,9 Hz
DB0DON JN58JR 438.57500 430.97500 -7.6 FM Donauwörth
DB0NG JO31NQ 438.57500 430.97500 -7.6 DMR Marl Motorola Relais DMR-DL
DB0BUX-B JO43UL 438.58750 430.98750 -7.6 DStar Buxtehude
DB0WA JO30AR 438.58750 430.98750 -7.6 DStar Aachen

Gateway DB0WA G,

Standardverlinkung zu DCS001E
DB0DRI JO41MS 438.58750 430.98750 -7.6 FM Pömbsen Multimode Relais
DB0HZG JN48MP 438.58750 430.98750 -7.6 DMR Holzgerlingen Multimode: DMR, DSTAR, C4FM
DB0STD JN69AF 438.60000 431.00000 -7.6 C4FM Burglengenfeld - Köblitzplatte
DB0STD JN69AF 438.60000 431.00000 -7.6 FM Burglengenfeld - Köblitzplatte
DB0FA JO52CV 438.60000 431.00000 -7.6 FM Faßberg CTCSS 94.8 Hz, Echolink 281537
DB0EK JO44UA 438.60000 431.00000 -7.6 C4FM Hennstedt FM/C4FM
DB0SR JN39MI 438.60000 431.00000 -7.6 DMR Heusweiler
DB0UHF JN48TW 438.60000 431.00000 -7.6 FM Kaisersbach Multimode FM / SSTV
DO0MAL JO63IS 438.60000 431.00000 -7.6 FM Malchin MM (Phone,SSTV,PSK31,RTTY, BPSK)
DO0FWH JO62AG 438.60000 431.00000 -7.6 FM Stresow
EL#40408
DB0THA JO50JP 438.60000 431.00000 -7.6 FM Schneekopf
DB0ZAV JO40JF 438.60000 431.00000 -7.6 C4FM Karben 127,3 Hz bei FM
DB0ZAV JO40JF 438.60000 431.00000 -7.6 FM Karben 127,3 Hz
DB0ZAV JO40JF 438.60000 431.00000 -7.6 DStar Karben
DB0OVM JO31TW 438.60000 431.00000 -7.6 FM

Fernmeldeturm

Münster

 Multimode Relais
DO0GEZ JO41VX 438.61250 431.01250 -7.6 FM Alfeld
DO0GEZ JO41VX 438.61250 431.01250 -7.6 C4FM Alfeld WireX Anbindung
DB0WAT JO31NL 438.61250 431.01250 -7.6 FM Wattenscheid
DB0HEI JO44NE 438.61250 431.01250 -7.6 C4FM Heide C4FM Wires-X 31570
DM0ESS JN57DM 438.61250 431.01250 -7.6 DMR Sonthofen / Allgaeu DMR+ ID: 262860
DM0BGH JN68KE 438.62500 431.02500 -7.6 FM Burghausen
DB0SKF JN48EK 438.62500 431.02500 -7.6 C4FM Freudenstadt

FM/C4FM Multimode,

FM Nutzung

CTCSS 71.9 Hz, DTFM-ID:31003
DB0HHH JO53CL 438.62500 431.02500 -7.6 DMR HH-Lohbrügge DMR-ID:262277
DB0WO JO33RF 438.62500 431.02500 -7.6 C4FM Leer Linkverbund DL-NORDWEST
DB0QF JO31GN 438.62500 431.02500 -7.6 FM Rheinberg via Gateway SSTV, PSK32, FAX u.a.
DB0HHH JO53CL 438.62500 431.02500 -7.6 C4FM HH-Lohbrügge WIRES-X node 27156;
DB0HHH JO53CL 438.62500 431.02500 -7.6 FM HH-Lohbrügge CTCSS 79,7Hz
DB0OUD JO62PM 438.62500 431.02500 -7.6 DMR Berlin Mitte DMR ID: 262120
DM0KWD JO51XL 438.62500 431.02500 -7.6 FM Halle / Saale
DB0HHH JO53CL 438.62500 431.02500 -7.6 DStar HH-Lohbrügge
DB0SA JO41KX 438.62500 431.02500 -7.6 FM Detmold FM, SSTV, RTTY, CTCSS 77 Hz.
DB0FUE JN59LL 438.62500 431.02500 -7.6 FM Fürth
DB0VEL JO31MI 438.63750 431.03750 -7.6 C4FM Velbert CTCSS: 67,0 Hz
DB0VEL JO31MI 438.63750 431.03750 -7.6 DMR Velbert DMR-ID: 262452
DB0BUC JO43WH 438.63750 431.03750 -7.6 DMR Buchholz

über TG 8 mit DB0AGM und

DB0WL verbunden
DB0IN JN58RS 438.63750 431.03750 -7.6 DMR Ingolstadt

zur Zeit außer Betrieb/

DMR ETSI und Brandmeister
DB0HZG JN48MP 438.63750 431.03750 -7.6 FM Holzgerlingen
DB0ZEA JO61BX 438.65000 431.05000 -7.6 DMR Zerbst DMR+ ID:
DB0TT JO31SL 438.65000 431.05000 -7.6 FM Schwerte

CTCSS 67Hz,

gekoppelt mit DB0DDO und

Wires-X Node: 17131
DB0SS JN49OD 438.65000 431.05000 -7.6 FM

Heilbronn

Wartberg


DB0NDS JO53KB 438.65000 431.05000 -7.6 C4FM Zernien FM/C4FM
DB0VKS JN39KG 438.65000 431.05000 -7.6 FM Völklingen
DB0SLF JO50QP 438.65000 431.05000 -7.6 DStar Saalfeld Saale Digital Multimode Test
DB0OL JO43CD 438.65000 431.05000 -7.6 FM JO43CD Rufton: 1750 Hz
EL#880675
DB0GIS JO40JN 438.65000 431.05000 -7.6 FM

Fernwald-

Steinbach
DB0WLG JO64VB 438.65000 431.05000 -7.6 FM Wolgast
DB0FFO JO72HD 438.65000 431.05000 -7.6 FM Eisenhüttenstadt Eochlin-Nord #769668
DB0ZEA JO61BX 438.65000 431.05000 -7.6 FM Zerbst FM: CTCSS 88.5
DB0DIN JO31JK 438.66250 431.06250 -7.6 FM Duisburg Ton: 1750 Hz
DB0STM JO42RK 438.66250 431.06250 -7.6 C4FM Klein Heidorn
DB0PI JO43TS 438.66250 431.06250 -7.6 FM Elmshorn trägergesteuert
DB0KLI JN48JC 438.66250 431.06250 -7.6 DMR Klippeneck
DB0MHL JO51FF 438.66250 431.06250 -7.6 FM Mühlhausen
DB0NU JO50IE 438.67500 431.07500 -7.6 FM Altenstein

Öffnen mit 1750 Hz Rufton

Echolink Nodenummer: 939467
DB0EON JO41MD 438.67500 431.07500 -7.6 FM

Edersee Hoch

speicherbecken 545m NN

 CTCSS 67 Hz
DB0EG JO32PC 438.67500 431.07500 -7.6 FM Schöppingen
DB0SFA JO42UV 438.67500 431.07500 -7.6 FM Dorfmark
DB0UA JN58LI 438.67500 431.07500 -7.6 FM Augsburg CTCSS 88,5Hz
DB0RB JN49HC 438.67500 431.07500 -7.6 FM Bruchsal
DB0MSP JO63MI 438.67500 431.07500 -7.6 FM Neustrelitz
DB0BW JN68QN 438.67500 431.07500 -7.6 FM Fürstenzell Passau

Tonruf 1750 Hz oder

Subton 71,9 Hz
DB0MYK JO30OJ 438.67500 431.07500 -7.6 FM Gänsehals Eifel nur mit CTCSS 103.5 Hz
DO0SOC JO54KI 438.67500 431.07500 -7.6 DMR Wandelwitz

MMDVM Selbstbaurelais

im Brandmeister-Netz
DB0OI JO52GG 438.67500 431.07500 -7.6 FM Braunschweig
DB0SAX JO61MH 438.67500 431.07500 -7.6 FM Collmberg CTCSS: TRX 67,0 Hz
DB0WA JO30AR 438.68750 431.08750 -7.6 DMR Aachen DMR-ID: 262402
DB0ROD JO42QH 438.68750 431.08750 -7.6 DMR

Rodenberg

am Deister

DMR ID: 262335,

BrandMeister
DB0FUL JO40UO 438.68750 431.08750 -7.6 FM

Fulda-

Hummelskopf
EL#963194
DB0OX JO33OO 438.70000 431.10000 -7.6 FM

Norden

Ostfriesland, Wasserturm

Svxlink mit Echolink,

CTCSS 123 Hz

oder 1750 Hz Ton
DF0HHH JO43WJ 438.70000 431.10000 -7.6 FM Rosengarten

FM/C4FM.

Repeater sendet nur FM,

empfängt aber C4FM + FM.

TX-CTCSS=67,0 Hz
DB0XS JN39GM 438.70000 431.10000 -7.6 FM Mettlach-Orscholz C4FM und Internet geplant
DB0XS JN39GM 438.70000 431.10000 -7.6 C4FM Mettlach-Orscholz Internetanbindung geplant
DF0HHH JO43WJ 438.70000 431.10000 -7.6 C4FM Rosengarten

FM/C4FM.

Repeater sendet nur FM,

empfängt aber C4FM + FM.

TX-CTCSS=67,0 Hz
DB0ST JN48NR 438.70000 431.10000 -7.6 FM Stuttgart
DB0TR JN67CR 438.70000 431.10000 -7.6 C4FM

Rosenheim

Hochries

 CTCSS 77,0 Hz, derzeit außer Betrieb
DB0TR JN67CR 438.70000 431.10000 -7.6 FM

Rosenheim

Hochries
DM0SAT-B JN47JS 438.70000 431.10000 -7.6 DStar

Singen

(Hohentwiel)
DB0GOE JO41XN 438.70000 431.10000 -7.6 DMR Bovenden

ID: 262347 /

BM262: TG9 Ref 4031
DB0FRG JN37WV 438.70000 431.10000 -7.6 FM Schauinsland Echolink 891536
DB0CSD JO60LR 438.70000 431.10000 -7.6 FM

Chemnitz -

Klaffenbach

Rufton 1750 Hz,

Echolink Node #506031
DB0GOE JO41XN 438.70000 431.10000 -7.6 FM Bovenden
DB0FA JO52CV 438.71250 431.11250 -7.6 DMR Faßberg DMR ID: 262341
DB0DDS JO31SL 438.71250 431.11250 -7.6 C4FM Schwerte
DM0TMH JN59SI 438.71250 431.11250 -7.6 FM Trautmanshofen
DB0WQ JO42HJ 438.71250 431.11250 -7.6 DMR Espelkamp DMR+ , Hytera-Relais
DB0DS JO31RL 438.71250 431.11250 -7.6 C4FM Dortmund C4FM
DB0XY JO51EU 438.72500 431.12500 -7.6 FM

Bocksberg

Goslar -

Hahnenklee

 Echolink: #278589
DB0KCH JO50PF 438.72500 431.12500 -7.6 FM

Gehülz-

Wasserturm
DB0RZ JN48SD 438.72500 431.12500 -7.6 FM Bussen (höchste Erhebung Landkreis Biberach) Echolink 44077
DB0BOH JO31HU 438.72500 431.12500 -7.6 FM Bocholt
DB0HHA JO53AO 438.72500 431.12500 -7.6 FM HH-Barmbek

verbunden mit

Teamspeak Funkerportal nur RX
DB0HRC JO61AG 438.72500 431.12500 -7.6 FM

Oebles -

Schlechtewitz

 Träger gesteuert!
DB0SWR JN49RQ 438.72500 431.12500 -7.6 FM Wertheim/Main

Öffnen mit CTCSS 88.5Hz

oder 1750Hz,

Echolink, Main-Tauber Relaisverbund
DB0ZOD JO62RM 438.72500 431.12500 -7.6 FM

Berlin

Friedrichshain

 FM
DB0YS JO40AX 438.72500 431.12500 -7.6 DMR Kreuztal FM / DMR Repeater. Node 262404
DB0BNV JO43HE 438.72500 431.12500 -7.6 FM

Bremen-

Vegesack
DB0KLE JO31BS 438.73750 431.13750 -7.6 FM Kleve
DM0MAX JO42IG 438.73750 431.13750 -7.6 FM Wiehengebirge

CTCSS TX 88,5 RX --

oder 1750Hz oder

SQL offen min 3sec

E:956106
DB0KOE JO30LW 438.73750 431.13750 -7.6 FM Köln

1750 Hz Rufton

oder 103,5 Hz CTCSS,

EL #8850
DB0HRF JO40FF 438.75000 431.15000 -7.6 FM Feldberg / Taunus
DF0ANN JN59PL 438.75000 431.15000 -7.6 FM Moritzberg CTCSS 77,0 Hz
DB0DI JO53DW 438.75000 431.15000 -7.6 FM Bad Segeberg
DB0WTV JO43BM 438.75000 431.15000 -7.6 FM Wilhelmshaven Echolink: EL #200060
DB0ZV JO31RJ 438.75000 431.15000 -7.6 FM Hagen
DB0BPY JO41PW 438.75000 431.15000 -7.6 FM JO41PX
DB0DES JO61CU 438.75000 431.15000 -7.6 FM Dessau-Roßlau
DB0JNA JO50TV 438.75000 431.15000 -7.6 FM Jena-Burgau

Tonsqelsh 88,5Hz

nur in der FM Ausgabe
DB0JNA JO50TV 438.75000 431.15000 -7.6 C4FM Jena-Burgau
DB0NBB JO63PN 438.75000 431.15000 -7.6 FM Neubrandenburg
DF0MHR JO31KK 438.76250 431.16500 -7.6 DMR Mühlheim Ruhr DMR-DL
DB0MAK JO60BA 438.77500 431.17500 -7.6 FM Marktredwitz, OT Haingrün

Rufton 1750Hz,

CTCSS 74.4Hz
DB0NI JO53FF 438.77500 431.17500 -7.6 FM Lüneburg
DB0HWR JN39JN 438.77500 431.17500 -7.6 DMR Weiskirchen Multimode C4FM / DMR
DB0HWR JN39JN 438.77500 431.17500 -7.6 FM Weiskirchen Multimode C4FM / DMR
DB0LOS JO72AH 438.77500 431.17500 -7.6 FM Rauen

Wide-Digi und 438,775 MHz

FM-Relais
DB0ORT JN48BN 438.77500 431.17500 -7.6 FM Rodeck
DB0NJ JN58TE 438.77500 431.17500 -7.6 FM München Freimann 1750 Hz
DB0QL JO41WA 438.77500 431.17500 -7.6 FM Bebra-Solz
DB0ZO JO42AE 438.77500 431.17500 -7.6 FM Döhrenberg
DB0EBA JN59MN 438.77500 431.17500 -7.6 FM

Erlangen

Tennenlohe

 Echolink EL #422274
DB0LE JO61CH 438.78750 431.18750 -7.6 FM Markranstädt
DB0CGN JO30KW 438.78750 431.18750 -7.6 FM Köln

TX: CTCSS Ton 74,4 Hz

RX: CTCSS 254,1 Hz
DB0TC JN58VK 438.80000 431.20000 -7.6 FM

Langenbach

Freising

 CTCSS 88,5
DB0XX JO52MF 438.80000 431.20000 -7.6 FM Helmstedt
DB0TD JN49XC 438.80000 431.20000 -7.6 FM Crailsheim
DB0XJ JO43RO 438.80000 431.20000 -7.6 FM Stade

Multirelais C4FM/FM/

(FM 67,0 Hz Subaudio )
EL#275703
DB0XJ JO43RO 438.80000 431.20000 -7.6 C4FM Stade

Multirelais C4FM/FM/Echolink

(FM 67,0 Hz Subaudio )
DB0SJ JO31JF 438.80000 431.20000 -7.6 FM Düsseldorf
DB0TC JN58VK 438.80000 431.20000 -7.6 C4FM

Langenbach

Freising

 438.8125 MHz momentan nicht in Betrieb
DB0BLO JO62RM 438.80000 431.20000 -7.6 C4FM Berlin-Hohenschönhausen

CTCSS 67Hz im TX FM

Wires-X Node: 17250
DB0OWL JO41HW 438.80000 431.20000 -7.6 FM Kumstonne (Oerlinghausen)
DB0GGW JN49HR 438.80000 431.20000 -7.6 FM

Zwingenberg

Melikobus

 1750 Hz
DB0ALB JN48LH 438.81250 431.21250 -7.6 FM Albstadt
DB0DAU JO30KE 438.81250 431.21250 -7.6 FM Mehren / Eifel
DB0HSK JO41DJ 438.81250 431.21250 -7.6 DMR Arnsberger Wald Brandmeister
DB0THS JO52EA 438.82500 431.22500 -7.6 FM Salzgitter - Bad
DB0SR JN39MI 438.82500 431.22500 -7.6 FM Heusweiler Echolink EL#56785
DB0HRB JO40GW 438.82500 431.22500 -7.6 FM

Sackpfeife

(Biedenkopf)
DO0RM JO63HJ 438.82500 431.22500 -7.6 FM Röbel Echolink #747184
DB0SH JO44RS 438.82500 431.22500 -7.6 FM Flensburg

Stadtrelais,

begrenzte Reichweite
DB0ODE JN49MH 438.82500 431.22500 -7.6 FM Obrigheim/Baden

DR1X z.Z. in Reparatur,

danach Mixmode

C4FM/FM möglich
DB0BS JO31OL 438.82500 431.22500 -7.6 C4FM Bochum mixed mode s.a.homepage
DB0REN JO50RK 438.82500 431.22500 -7.6 FM

Lehesten

Wetzstein /

Rennsteig

 Echolink: EL#579989
DB0OZ JO43JC 438.82500 431.27500 -7.6 FM Bremen
DB0GK JN49MA 438.83750 431.23750 -7.6 DMR

Hohenhaslach -

Hohe Reute

 DMR-Plus ID: 262766
DO0TPB JO53HJ 438.83750 431.23750 -7.6 C4FM Basedow

Multimode

DMR DSTAR YSF Analog Echolink, Yaesu Node 17197
DB0ERK JO31CC 438.83750 431.23750 -7.6 FM Wegberg CTCSS 94,8 Hz
DB0ERK JO31CC 438.83750 431.23750 -7.6 C4FM Wegberg CTCSS 94,8 Hz
DB0UG JO41LT 438.83750 431.23750 -7.6 DMR

Paderborn-

Eggegebirge

 ID: 262401
DO0TPB JO53HJ 438.83750 431.23750 -7.6 FM Basedow

Multimode

DMR DSTAR YSF Analog

Echolink #272360, 94.8Hz
DO0TPB JO53HJ 438.83750 431.23750 -7.6 DStar Basedow

Multimode

DMR DSTAR YSF Analog Echolink
DO0TPB JO53HJ 438.83750 431.23750 -7.6 DMR Basedow

Multimode

DMR DSTAR YSF Analog Echolink
DB0WES JO31HP 438.85000 431.25000 -7.6 FM Wesel
DB0CBS JO71ER 438.85000 431.25000 -7.6 FM Cottbus Echolink via DO6NC-L , ID: 425399
DB0ZU JN57LK 438.85000 431.25000 -7.6 FM Zugspitze
DB0WZ JN49WS 438.85000 431.25000 -7.6 FM Würzburg CTCSS: 88,5Hz
DB0TM JO41QH 438.85000 431.25000 -7.6 FM Fernmeldeturm Essigberg
DB0TM JO41QH 438.85000 431.25000 -7.6 C4FM Fernmeldeturm Essigberg
DB0FS JO43XO 438.85000 431.25000 -7.6 FM HH-Lokstedt

TX CTCSS 88,5 Hz

oder mit DTMF * öffnen, kein Tonruf,

RX-Squelch: CTCSS 88,5 Hz
EL#329356
DB0DTM JO30NR 438.85000 431.25000 -7.6 C4FM Bonn Wires-X ID: 17130
DB0DTM JO30NR 438.85000 431.25000 -7.6 FM Bonn Ruf-Ton 1750 Hz
DM0MGB JO52TD 438.85000 431.25000 -7.6 FM Magdeburg
DB0GER JO60BV 438.85000 431.25000 -7.6 FM Gera
DB0VV JN39PQ 438.85000 431.25000 -7.6 DMR

Idar-Oberstein/

Hillschied

 FM 88.5Hz/DMR
DO0GG JN49FV 438.85000 431.25000 -7.6 FM Groß-Gerau Trägergesteuert; EL#281418
DB0XW JO33UN 438.85000 431.25000 -7.6 C4FM Wittmund Linkverbund DL-NORDWEST
DB0DT JO40BP 438.86250 431.26250 -7.6 FM Berg Fuchskaute
DB0QX JO51MQ 438.87500 431.27500 -7.6 FM Ramberg/Harz

Ramberg bei

Friedrichsbrunn im Harz
DB0CJ JN59WK 438.87500 431.27500 -7.6 FM Amberg
DM0FFL JN68BN 438.87500 430.77500 -8.1 DStar Landshut
DB0QH JO41DJ 438.87500 431.27500 -7.6 FM Meschede Echolink: EL#552863
DB0TUD JO61UA 438.87500 431.27500 -7.6 FM Dresden Rufton 1750 Hz
DO0OHO JO54LI 438.87500 431.27500 -7.6 DMR Heiligenhafen

Hytera RD625 im

Brandmeister-Netz
DB0GL JO30NX 438.87500 431.27500 -7.6 DMR Bergisch Gladbach Marienkrankenhaus
DB0XQ JN48HV 438.87500 431.27500 -7.6 FM Keltern-Dietlingen CTCSS 94,8
DB0SUN JO42SF 438.88750 431.28750 -7.6 FM Deister
DB0ZZ JO61CA 438.88750 431.28750 -7.6 FM Bockwitz bei Zeitz
DB0RP JN68BX 438.90000 431.30000 -7.6 FM Regensburg Echolink-Nr. 199766
DB0WBE JO61SL 438.90000 431.30000 -7.6 FM Winterberg bei Elsterwerda
DB0GSH JO51EV 438.90000 431.30000 -7.6 FM Steinberg
DB0OVG JO42EU 438.90000 431.30000 -7.6 FM Goldenstedt duplex
DB0FB JN47AU 438.90000 431.30000 -7.6 FM

Feldberg /

Schwarzwald
DB0XL JO53HV 438.90000 431.30000 -7.6 C4FM Lübeck FM/C4FM
DB0TE JN48XK 438.90000 431.30000 -7.6 FM Ulm Echolink Node # 603744
DB0STB JN49QB 438.90000 431.30000 -7.6 FM Stocksberg
DB0PSW JO63XM 438.90000 431.30000 -7.6 FM Pasewalk
DB0VT JN59KV 438.90000 431.30000 -7.6 FM Frensdorf mit Tonruf öffnen
DB0NG JO31NQ 438.90000 431.30000 -7.6 DMR Marl Hytera Relais DCS4006 Ruhrgebiet
DB0XL JO53HV 438.90000 431.30000 -7.6 FM Lübeck

FM + C4FM in,

FM out, keine Vernetzung zu anderen Relais
DB0ROF JO41WA 438.90000 431.30000 -7.6 DMR Bebra DMR-ID: 262632 Brandmeister
DB0XXL JO42MF 438.92500 431.32500 -7.6 FM Bückeburg kein Subton
DB0CHA JN69IH 438.92500 431.32500 -7.6 FM Eschlmais CTCSS 71,9Hz
DB0ZE JO53BM 438.92500 431.32500 -7.6 DMR HH-Moorfleet Brandmeister, über TG 8, Zeit. 2 con. zu DB0FS, weltweit TG 26221,lokal: TG 9
DB0ET JO33MJ 438.92500 431.32500 -7.6 FM Emden
DB0TFK JN39JO 438.92500 431.32500 -7.6 FM

Teufelskopf

Waldweiler
DB0LBH JO61JF 438.92500 431.32500 -7.6 FM

Grimma

Deditzhöhe
DM0EA JO50DX 438.92500 431.32500 -7.6 FM Eisennach
DB0KX JO31EG 438.92500 431.32500 -7.6 FM Viersen EL#501790
DB0BR JO62QL 438.92500 431.32500 -7.6 FM Berlin Tempelhof, Hessenring 47 sprachgesteuert
DB0LGH JO42UK 438.93750 431.33750 -7.6 FM Langenhagen CTCSS 100,0
DB0LGH JO42UK 438.93750 431.33750 -7.6 C4FM Langenhagen WireX Anbindung
DB0DOB JN49BO 438.93750 431.33750 -7.6 C4FM Lautersheim C4FM und FM Relais
DB0DOB JN49BO 438.93750 431.33750 -7.6 FM Lautersheim C4FM und FM Relais
DB0OAL JN57JN 438.93750 431.33750 -7.6 FM

Tegelberg /

Allgäu

 1750Hz Ton
DM0HA JO31RI 438.93760 431.33750 -7.6 FM Hagen
DB0XN JO44LP 438.95000 431.35000 -7.6 FM Bredstedt
DB0WAS JO40XL 438.95000 431.35000 -7.6 FM

Wasserkuppe /

Rhön

 TX: Storno 662
DB0NFL JO71HR 438.95000 431.35000 -7.6 FM Forst / Lausitz Echolink Node #584976
DM0FFL JN68BN 438.95000 431.35000 -7.6 FM Landshut CTCSS 71,9 Hz
DB0SE JO30GL 438.95000 431.35000 -7.6 FM Kall / Eifel Tonruf 1750 Hz
DB0TI JN48OM 438.95000 431.35000 -7.6 FM Reutlingen
DB0SBB JO60LM 438.95000 431.35000 -7.6 FM Scheibenberg
DB0DAM JO42CN 438.95000 431.35000 -7.6 FM Dammer Berge
DB0IS JO31UJ 438.96250 431.36250 -7.6 FM Iserlohn 1750Hz
DB0NW JN49BH 438.96250 431.36250 -7.6 C4FM Neustadt a.d. Weinstrasse 67,0 Hz Rx
DB0NW JN49BH 438.96250 431.36250 -7.6 FM Neustadt a.d. Weinstrasse
DB0QG JN69GK 438.97500 431.37500 -7.6 FM Altenschneeberg
DB0TG JO43JG 438.97500 431.37500 -7.6 FM Teufelsmoor
DB0LUC JO61TS 438.97500 431.37500 -7.6 FM Gehren/Heideblick EL-Node 287117
DO0PB JO41GN 438.97500 431.37500 -7.6 FM Paderborn / Büren
DB0SLF JO50QP 438.97500 431.37500 -7.6 FM Saalfeld Saale
DB0VM JN58SD 438.97500 431.37500 -7.6 FM München Westend 1750 Hz
DB0TDR JO53VW 438.97500 431.37500 -7.6 FM Satow ThueringenLink connect db0fts.de
DB0SMB JO52FD 438.97500 431.37500 -7.6 FM Salzgitter FM / C4FM, TRX 100 Hz
DB0SMB JO52FD 438.97500 431.37500 -7.6 C4FM Salzgitter FM / C4FM, TRX 100 Hz
DB0CA JO31NF 438.97500 431.37500 -7.6 FM Wuppertal 1750Hz Rufton oder DTMF 0
DB0SHG JO42QE 438.98750 431.38750 -7.6 FM Süntelturm
DM0SC JN59MH 438.98750 431.38750 -7.6 FM Schwabach
DM0KR JO31GH 438.98750 431.38750 -7.6 FM Krefeld

CTCSS 123.0 Hz,

1750Hz-Ton,

DMTF Ziffer 2 zum Öffnen
PD0ZRY JO22QD 438.98750 431.38750 -7.6 DMR

Amersfoort

Niederlande
DB0ZD JN57CM 439.00000 431.40000 -7.6 FM Mittagberg

Echolink 24 Std. Online

75518 = Node Number
DB0MAK JO60BA 439.00000 431.40000 -7.6 FM Marktredwitz, OT Haingrün Rufton 1750Hz
DB0KIL JO54BH 439.00000 431.40000 -7.6 FM Kiel
DB0HRR JO40RT 439.00000 431.40000 -7.6 FM Breitenbach

bis Sommer 2018

wg. DVBT-Umbau abgeschaltet
DB0HS JO62OO 439.00000 431.40000 -7.6 C4FM 13503 Berlin - Heiligensee CTCSS 67 Hz auf dem FM-Träger
DB0HAL JO51XO 439.00000 431.40000 -7.6 FM Petersberg / Saale
DB0TN JN48BI 439.00000 431.40000 -7.6 FM Brandenkopf / Oberharmersbach
DB0YI JO42XC 439.00000 431.40000 -7.6 FM Sonnenhof bei Hildesheim Stadtrelais
DB0SC JN49VN 439.00000 431.40000 -7.6 FM Königshofen CTCSS 91.5Hz
DB0SC JN49VN 439.00000 431.40000 -7.6 C4FM Königshofen
DB0SK JO30LW 439.00000 431.40000 -7.6 FM Köln
DB0PD JO31RW 439.00000 431.40000 -7.6 FM Nottuln 1750
DB0DEL JO43HB 439.00000 431.40000 -7.6 FM Delmenhorst 1750 Hz
DB0HHW JO43TQ 439.01250 431.41250 -7.6 FM Uetersen Echolink 864598
DB0HFD JO42ID 439.01250 431.41250 -7.6 DMR Herford Brandmeister mit Hytera Repeater
DB0JJ JO50SU 439.01250 431.41250 -7.6 FM Jena - Maua Echolink Node #569654
DB0NY JO31TB 439.02500 431.42500 -7.6 FM Gummersbach
DB0AMK JO52XN 439.02500 431.42500 -7.6 FM Tangermünde

1750 Hz für 100ms oder

DTMF 1
DB0CP JN58RN 439.02500 431.42500 -7.6 FM Pfaffenhofen
DB0FBG JO60QW 439.02500 431.42500 -7.6 FM Freiberg Bürogebäude Halsbrücker Strasse 34
DB0LIC JO50MD 439.02500 431.42500 -7.6 FM

Lichtenfels -

Herberg
DB0MA JN49FL 439.02500 431.42500 -7.6 FM Mannheim
DB0EE JO31DU 439.02500 431.42500 -7.6 FM Emmerich Echolink Node: #482691
DB0UG JO41LT 439.02500 431.42500 -7.6 FM

Paderborn-

Eggegebirge
DB0BRO JO51HT 439.03750 431.43750 -7.6 C4FM Brocken Harz

Brockenhaus 88.5Hz

C4FM-FM Multimode
DM0WL JO53CI 439.03750 431.43750 -7.6 C4FM Winsen/Luhe FM/C4FM 67 Hz
DF0MHR JO31KK 439.03750 431.43750 -7.6 DMR Mühlheim Ruhr DMR Brandmeister
DB0OHR JN49SE 439.03750 431.43750 -7.6 FM Öhringen
DB0OHR JN49SE 439.03750 431.43750 -7.6 C4FM Öhringen
DB0WP JN39RM 439.05000 431.45000 -7.6 FM

Potzbergturm

auf dem

Potzberg
DB0SL JN68MV 439.05000 431.45000 -7.6 FM Greising

CTCSS 71,9Hz,

Echolink 691274
DB0ESW-R JO51AE 439.05000 431.45000 -7.6 DMR Eschwege

Echolink Node #439050,

CTCSS 67 Hz,

DMR+262628 / BM 26261
DB0ESW JO51AE 439.05000 431.45000 -7.6 DMR Eschwege DMR-Plus ID: 262628
DB0HEI JO44NE 439.05000 431.45000 -7.6 FM Heide
DB0ESW JO51AE 439.05000 431.45000 -7.6 FM Eschwege

Echolink Node #439050,

CTCSS 67 Hz
DB0SX JO62PM 439.05000 431.45000 -7.6 FM Berlin West-End Zur Zeit ausser Betrieb
DB0KUE JO54UD 439.05000 431.45000 -7.6 FM Kühlungsborn
DB0SG JO30OQ 439.05000 431.45000 -7.6 FM

Ölberg,

Siebengebirge

nahe Königswinter
DB0ZWU JO60GQ 439.05000 431.45000 -7.6 FM Zwickau Echolink- Node 378030
DB0ZWI JO60FR 439.05000 431.45000 -7.6 FM Zwickau
DB0MSK JO40SB 439.05000 431.45000 -7.6 DMR Lohr Gemuenden DMR+ ID: 262848
DB0VW JO52IJ 439.05000 431.45000 -7.6 FM Wolfsburg - Detmerode
DB0VL JO32SM 439.05000 431.45000 -7.6 FM Lingen-Thuine / Ems CTCSS 123 Hz
DB0IK JO50NV 439.06250 431.46250 -7.6 FM Riechheimer Berg Echolink Node: DB0IK-R 285387
DB0NA JO31ML 439.07500 431.47500 -7.6 FM Essen 67Hz CTCSS
DB0HEL JO34WE 439.07500 431.47500 -7.6 FM Helgoland FM/C4FM
DB0HEL JO34WE 439.07500 431.47500 -7.6 DMR Helgoland DMR-Plus - ID: 262233
DB0POB JN58QP 439.07500 431.47500 -7.6 FM Pobenhausen

AllStarlink Node 28175 /

Echolink EL#85851
DB0HEL JO34WE 439.07500 431.47500 -7.6 C4FM Helgoland FM/C4FM
DB0BH JN38XQ 439.07500 431.47500 -7.6 DMR

Buehl /

Schwarzwald
DB0BH JN38XQ 439.07500 431.47500 -7.6 FM

Buehl /

Schwarzwald

 CTCSS 94,8 Hz
DB0PM JN57WS 439.07500 431.45700 -7.6 FM

Brenten

Brentenspitz /

Hausham

 Koppelung mit DB0TOL
DB0RQ JN69BW 439.07500 431.47500 -7.6 FM Fuchsmühl
DB0WOF JO61DQ 439.07500 431.47500 -7.6 FM Wolfen
DB0OHA JO51EP 439.07500 431.47500 -7.6 FM Herzberg
DB0HEL JO34WE 439.07500 431.47500 -7.6 DStar Helgoland
DB0WTL JN49QC 439.07500 431.47500 -7.6 FM Loewenstein - Wasserturm Combined with DB0WTL 10m-Repeater
DB0VEL JO31MI 439.08750 431.48750 -7.6 FM Velbert CTCSS;123Hz
DB0HBG JN59GB 439.08750 431.48750 -7.6 FM Hesselberg
DB0ZEH JO62PW 439.10000 431.50000 -7.6 FM Zehdenick Echolink #359502
DB0LAU JO70HU 439.10000 431.50000 -7.6 FM Lausche Lausche-Relais im Zittauer Gebirge Nähe tschechischer Grenze
DB0RP JN68BX 439.10000 431.50000 -7.6 DMR Regensburg
DB0ZP JO42PN 439.10000 431.50000 -7.6 FM Linsburg Echolink-Node#: 357496
DB0PC JO54IF 439.10000 431.50000 -7.6 C4FM Bungsberg FM/C4FM 67 Hz
DB0HK JO40OM 439.10000 431.50000 -7.6 FM

Hoherodskopf -

Schotten
DB0PC JO54IF 439.10000 431.50000 -7.6 FM Bungsberg 67 Hz FM | FM/C4FM Dual Mode
DB0ZT JN39QH 439.10000 431.50000 -7.6 FM Käshofen 100 Hz
DB0ZT JN39QH 439.10000 431.50000 -7.6 C4FM Käshofen Multimode 77Hz CTCSS
DB0ZT JN39QH 439.10000 431.50000 -7.6 DMR Käshofen

Multimode 77Hz CTCSS

DMR-Node ID: 262506
DB0XO JO30IW 439.10000 431.50000 -7.6 FM

Bergheim

(Glessener Höhe)
DB0WOF JO61DQ 439.10000 431.50000 -7.6 DMR Wolfen Brandmeister
DB0ABB JO41UO 439.10000 431.50000 -7.6 FM Adelebsen
DB0AV JN67BU 439.10000 431.50000 -7.6 FM Rosenheim - Stadt (Fernmeldeturm) Rufton1750 Hz
DB0HH JO31TW 439.10000 431.50000 -7.6 FM

Fernmeldeturm

Münster
DM0HW JO43SX 439.11250 431.51250 -7.6 C4FM Hungriger Wolf FM/C4FM
DB0KLN JN39VK 439.11250 431.51250 -7.6 FM Kaiserslautern
DB0ERZ JO60HK 439.11250 431.51250 -7.6 FM Eibenstock

FM/C4FM -

CTCSS 71,9 TRX
DB0RO JN49AF 439.12500 431.52500 -7.6 FM Frankweiler
DB0LH JO42IE 439.12500 431.52500 -7.6 FM Löhne
DB0TRS JN67HU 439.12500 431.52500 -7.6 FM

Hochberg,

Traunstein

 Mixed Mode: FM + C4FM
DB0AVR JO30CS 439.12500 431.52500 -7.6 FM Stolberg
DB0HT JO43UG 439.12500 431.52500 -7.6 FM Tostedt
DB0HBP JO52CH 439.12500 431.52500 -7.6 FM Peine

1750 Hz zum Öffnen,

echolink #728174
DB0NX JO31TH 439.12500 431.52500 -7.6 FM Nachrodt
DB0KYF JO51MJ 439.12500 431.52500 -7.6 FM Bad Frankenhausen Kulpenberg

Wieder in betrieb,

Erweiterung für

C4FM,

DMR und DStar in Planung
DB0GJ JN59MO 439.12500 431.52500 -7.6 FM Erlangen
DB0ABX JN57NO 439.13750 431.53750 -7.6 FM Oberammergau - Laberberg
DB0BRO JO51HT 439.13750 431.53750 -7.6 DMR Brocken Harz

Brockenhaus 88.5Hz

DMR-FM Multimode
DB0WOL JO62XR 439.15000 431.55000 -7.6 FM Bad Freienwalde Wollenberg
DB0RDT JN58PT 439.15000 431.55000 -7.6 FM Tauberfeld
DB0HUS JO44ML 439.15000 431.55000 -7.6 FM Husum
DB0NAI JO50TI 439.15000 431.55000 -7.6 FM Langes Bühl bei Steinbach
DB0VER JO42PX 439.15000 431.55000 -7.6 DMR Verden

Subaudio 67 Hz,

DMR Hytera 4003
DB0LR JO41FE 439.15000 431.55000 -7.6 FM Kahler Asten / bei Winterberg

DB0LR

erfordert einen Subaudioton von 67Hz,

Relaisverbund mit DB0BRH/

Heidelstein,Rhön
DB0VER JO42PX 439.15000 431.55000 -7.6 FM Verden Subaudio 67 Hz
DM0LEI JO61FI 439.15000 431.55000 -7.6 FM Leipzig analog, Echolink
DB0BKR JN39WT 439.16250 431.56250 -7.6 FM Bad Kreuznach
DB0TS JN69EM 439.16250 431.56250 -7.6 DMR Am Eisenberg

CTCSS 203,5Hz,

DMR-ID: 262870
DM0MW JO60LX 439.16250 431.56250 -7.6 FM Mittweida SVX-Link Node 972538
DB0MTZ JN48PM 439.16250 431.56250 -7.6 FM Metzingen Echolink-Node: #293767
DB0MI JN49PS 439.17500 431.57500 -7.6 FM Moenchberg auch APRS-Digi
DB0BIB JN48VC 439.17500 431.57500 -7.6 FM Biberach an der Riß

SvxLink: DB0BIB-R 593855,

QTH: WBH Hölzle,

Betreiber DARC OV-P21
DB0EN JO31PH 439.17500 431.57500 -7.6 FM Sprockhövel

Betriebsort: Hobeuken 11;

45549 Sprockhövel
DB0EWB JO43ML 439.17500 431.57500 -7.6 FM Oerel-Barchel

C4FM/FM EL 47666 zeitweise,

ID 17209 Raum 27209
DB0EWB JO43ML 439.17500 431.57500 -7.6 C4FM Oerel-Barchel C4FM/FM EL 47666 zeitweise (duplicate)
DB0SAG JN39HS 439.17500 431.57500 -7.6 FM Trier
DB0OR JO51CR 439.17500 431.57500 -7.6 FM Osterode
DB0BEL JO62GD 439.17500 431.57500 -7.6 FM Bad Belzig
DB0SON JO50OJ 439.17500 431.57500 -7.6 FM Sonneberg Echolink Node #460935
DB0DB JN37US 439.17500 431.57500 -7.6 FM

Badenweiler/

Hochblauen

 C4FM / FM, CTCSS 100Hz
DB0DB JN37US 439.17500 431.57500 -7.6 C4FM

Badenweiler/

Hochblauen

 C4FM / FM-> CTCSS 100Hz
DB0ST JN48NR 439.18750 431.58750 -7.6 DMR Stuttgart Brandmeister
DB0ZO JO42AE 439.18750 145.16250 -294 FM Döhrenberg 123 Hz
DB0ZO JO42AE 439.18750 145.16250 -294 C4FM Döhrenberg 123 Hz Crossband
DB0LEV JO31MA 439.18750 431.58750 -7.6 FM Leverkusen
DB0SLB JN39TN 439.18750 431.58750 -7.6 FM

Rothselberg

Selberg

 CTCSS 77,0 Hz trägergesteuert
DB0SLB JN39TN 439.18750 431.58750 -7.6 C4FM

Rothselberg

Selberg

 CTCSS 77,0 Hz trägergesteuert
DB0AA JN58BS 439.20000 431.60000 -7.6 FM Oberkochen Bandbreitte: NARROW Rufton: 1750 Hz Echolink: 394461
DB0WBG JO61GV 439.20000 431.60000 -7.6 FM

Lutherstadt

Wittenberg
DB0HRH JN47EO 439.20000 431.60000 -7.6 FM Küssaburg Echolink 831754, Hochrhein
DB0TVI JO50FU 439.20000 431.60000 -7.6 FM Inselsberg
DB0XH JO43VN 439.20000 431.60000 -7.6 C4FM HH-Blankenese SVX Link - Multimode_DB0SY-R
DB0FHF JO44RS 439.20000 431.60000 -7.6 FM Flensburg
DB0PIB JO71EC 439.20000 431.60000 -7.6 DMR Großer Picho DMR-ID: 262929
DB0XH JO43VN 439.20000 431.60000 -7.6 FM HH-Blankenese

FM_Echo-Link_

DB0XH-R_CTCSS 79,7Hz
DB0XH JO43VN 439.20000 431.60000 -7.6 DStar HH-Blankenese Multimode_SVX-Link
DB0XH JO43VN 439.20000 431.60000 -7.6 DMR HH-Blankenese Multimode_SVX-Link
DB0FUS JO42VJ 439.20000 431.60000 -7.6 C4FM Hannover FM mit 85,4 Hz CTCSS-Subaudioton
DB0FUS JO42VJ 439.20000 431.60000 -7.6 FM Hannover FM mit 85,4 Hz CTCSS-Subaudioton
DB0PIB JO71EC 439.20000 431.60000 -7.6 FM Großer Picho Echolink 626527
DB0PIB JO71EC 439.20000 431.60000 -7.6 C4FM Großer Picho
DB0NGU JO32KL 439.20000 431.60000 -7.6 FM Uelsen
DB0NGU JO32KL 439.20000 431.60000 -7.6 C4FM Uelsen
DB0SRE JO31OO 439.21250 431.61250 -7.6 C4FM Recklinghausen

Mix-Mode mit FM-narrow,

DCS Codesquelch 606 RX+TX
DB0WTL JN49QC 439.21250 431.61250 -7.6 DMR Loewenstein - Wasserturm Brandmeister
DB0ARB JN69NC 439.22500 431.62500 -7.6 DMR Großer Arber
DB0ARB JN69NC 439.22500 431.62500 -7.6 DStar Großer Arber
DB0ARB JN69NC 439.22500 431.62500 -7.6 FM Großer Arber CTCSS 71,9Hz
DM0GZ JN58EM 439.22500 431.62500 -7.6 FM Grundremmingen Rufton: 1750 Hz ca 0,2 Sek
DM0GZ JN58EM 439.22500 431.62500 -7.6 FM Grundremmingen Rufton: 1750 Hz ca 0,2 Sek
DB0EFT JO50MW 439.22500 431.62500 -7.6 FM Erfurt ztw. EL Node Nr.600552
DM0RLB JO61JA 439.22500 431.62500 -7.6 FM Rochlitzer Berg
DO0SAW JO52NU 439.22500 431.62500 -7.6 FM Salzwedel Echolink Test EL#275595
DB0RR JO30OW 439.22500 431.62500 -7.6 FM Rösrath
DO0ERZ JO60JQ 439.22500 431.62500 -7.6 FM Thalheim/Sachsen - Tabakstanne CTCSS 67,0 Hz
DB0HAT JO31VQ 439.22500 431.62500 -7.6 FM Hamm

EL: 547142,Verbunden über

HAMNET mit dem

Ruhrlink-Netz,ruhrlink.org
DB0TVH JO42UJ 439.23750 431.63750 -7.6 FM Hannover
DM0UHF JN48TW 439.23750 431.63750 -7.6 C4FM Erkelenz Subaudio: 94,8 TRX
DB0UM JO73CE 439.23750 431.63750 -7.6 FM Casekow
DB0THF JO50NM 439.23750 431.63750 -7.6 FM

Neuhaus am

Rennweg
DB0ROL JN58RC 439.23750 431.63750 -7.6 FM München 141,3 Hz
DB0ROL JN58RC 439.23750 431.63750 -7.6 C4FM München 141,3 Hz
DB0EEE JN58DA 439.25000 431.65000 -7.6 FM Erkheim

Echolink #729451,

Subton 136,5 Hz

KANN zum Auftasten

verwendet werden
DB0GKN JN49OE 439.25000 431.65000 -7.6 FM Heilbronn
DB0BKN JN68JE 439.25000 431.65000 -7.6 FM Eschlberg Linked with DB0RKS
DM0TMM JO52TD 439.25000 431.65000 -7.6 FM Magdeburg
DB0UHC JO31HB 439.25000 431.65000 -7.6 FM

Grevenbroich

(Vollrather Höhe)

 CTCSS 94.8 Hz
DB0BI JO42FA 439.25000 431.65000 -7.6 FM Hünenburg (bei Bielefeld)
DB0HHG JO41WM 439.25000 431.65000 -7.6 FM Göttingen - Hetjershausen Echolink Node #391088
DB0VOX JN59MK 439.25000 431.65000 -7.6 FM Nürnberg FMT Echolink Node -Nr # 71665
DB0FHH JO42UI 439.26250 431.66250 -7.6 C4FM Hannover FM/C4FM
DB0FHH JO42UI 439.26250 431.66250 -7.6 FM Hannover CTCSS: 85.4 Hz
DB0LZ JN39ML 439.27500 431.67500 -7.6 DMR

Schaumberg,

Tholey
DB0SML JO61EH 439.27500 431.67500 -7.6 C4FM Leipzig

Subton 67,0 Hz

DCS Code 073

C4FM Wires-X Node: 18967
DB0SML JO61EH 439.27500 431.67500 -7.6 FM Leipzig
DB0FHN JN59NK 439.27500 431.67500 -7.6 FM Nürnberg FHN
DB0CEL JO52BP 439.27500 431.67500 -7.6 DMR Celle
DB0THE JO51EL 439.27500 431.67500 -7.6 FM Kaltohmfeld
DB0JUI JO33MQ 439.27500 431.67500 -7.6 DMR Juist DMR+ ID: 262305
DB0JUI JO33MQ 439.27500 431.67500 -7.6 FM Juist Echolink-Node: 941134
DO0BAB JO53JN 439.27500 431.67500 -7.6 FM Gudow
DB0END JO31PH 439.27500 431.67500 -7.6 DMR

Ennepetal-

Stüting

 DMR-ID: 262407
DB0BLO JO62RM 439.27500 431.67500 -7.6 FM Berlin-Hohenschönhausen

Echolink #48880,

1750 Hz Rufton
DB0LZ JN39ML 439.27500 431.67500 -7.6 FM

Schaumberg,

Tholey

 CTCSS 71,9 Hz
DB0GEL JO40OF 439.27500 431.67500 -7.6 FM Gelnhausen (Schnepfenkopf)
DB0WI JO31CC 439.28750 431.68750 -7.6 C4FM

Wegberg -

Wildenrath

 bei FM CTCSS 94,8 Hz
DB0HX JO41QS 439.28750 431.68750 -7.6 FM Höxter Echolink #438372
DB0AMK JO52XN 439.28750 431.68750 -7.6 DMR Tangermünde

DMR an BM original und

DMR +

9Voran, C4FM an YSF
DB0WI JO31CC 439.28750 431.68750 -7.6 FM

Wegberg -

Wildenrath

 bei FM CTCSS 94,8 Hz
DO0SMZ JN49CX 439.30000 431.70000 -7.6 DMR Mainz DMR-ID: 262592
DB0SPB JO70IX 439.30000 431.70000 -7.6 FM Spitzbergbaude

Nähe Spitzberg bei Oderwitz

im Zittauer Gebirge aus APRS.fi
DB0OX JO33OO 439.30000 431.70000 -7.6 C4FM

Norden

Ostfriesland, Wasserturm

MMDVM-Multimode:

YSF Link zu DE Germany
DB0OX JO33OO 439.30000 431.70000 -7.6 DMR

Norden

Ostfriesland, Wasserturm

MMDVM-Multimode:

DMR+ Link zu TG4003 (Elbe-Weser)
DB0OX JO33OO 439.30000 431.70000 -7.6 DStar

Norden

Ostfriesland, Wasserturm

MMDVM-Multimode:

DCS Link zu DCS001 D (Elbe-Weser)
DB0MIR JN58OB 439.30000 431.70000 -7.6 FM

Inning am

Ammersee
DB0RAG JO62SG 439.30000 431.70000 -7.6 FM Ragow FM, 1750Hz, RU744
DM0KB-U JN47OP 439.30000 431.70000 -7.6 DMR Konstanz DMR plus
DM0IZH JO43SW 439.30000 431.70000 -7.6 FM Itzehoe Multimode
DB0ADB JN59KV 439.30000 431.70000 -7.6 DMR Bamberg
DB0WGS JN68VO 439.30000 431.70000 -7.6 FM

Wegscheid

Ponzaun
DB0WET JO31QI 439.30000 431.70000 -7.6 FM Wetter

Echolink Node # 8070

(Ruhrlink)
DB0LMM JO61EI 439.30000 431.70000 -7.6 FM Leipzig Ton 1750 Hz
DB0ROD JO42QH 439.30000 431.70000 -7.6 FM

Rodenberg

am Deister
DB0II JO31EE 439.31250 431.71250 -7.6 DMR Mönchengladbach DMR-ID: 262435
DB0CCC JO52BP 439.31250 431.71250 -7.6 FM Celle
DM0ESS JN57DM 439.31250 431.71250 -7.6 C4FM

Sonthofen /

Allgaeu
DB0PBS JO41JR 439.31250 431.71250 -7.6 FM Paderborn CTCSS 136,5 Hz
DB0BRH JO50AL 439.31250 431.71250 -7.6 FM Heidelstein mit DB0LR gekoppelt
DB0ULR JN58SC 439.32500 431.72500 -7.6 FM München Solln FM NXDN
DB0PL JO31NO 439.32500 431.72500 -7.6 FM Herten 67Hz CTCSS
DB0LP JN59UD 439.32500 431.72500 -7.6 FM Parsberg Echolink 273458
DB0GRI JN68OK 439.32500 431.72500 -7.6 FM Stadtplatz 3, Bad Griesbach im Rottal CTCSS 88,5Hz
DB0IZ JO43RV 439.32500 431.72500 -7.6 FM Krempermoor Multimode
DB0VS JN48EC 439.32500 431.72500 -7.6 DMR Mönchsweiler Multimode
DB0VS JN48EC 439.32500 431.72500 -7.6 C4FM Mönchsweiler Multimode
DB0VS JN48EC 439.32500 431.72500 -7.6 DStar Mönchsweiler Multimode
DB0VS JN48EC 439.32500 431.72500 -7.6 FM Mönchsweiler Multimode
DB0LY JO63PF 439.32500 431.72500 -7.6 FM Lychen

Echolink Node 519576

Allstarlink Node 29146
BD0HSB JO51HT 439.32500 431.72500 -7.6 FM Brocken Brockenbahnhof HSB
DB0VA JO40BC 439.32500 431.72500 -7.6 FM Taunusstein öffnen mit 1750 Hz
DB0FMS JN48OM 439.33750 431.73750 -7.6 DMR Reutlingen Brandmeister
DB0NN JO42PX 439.33750 431.73750 -7.6 FM Holtum-Geest bei Verden.
DB0FWS JO50CB 439.33750 431.73750 -7.6 FM Schweinfurt Ton 1750 Hz
DB0OSN JO42AG 439.35000 431.75000 -7.6 FM Osnabrück
DB0ERG JN68DQ 439.35000 431.75000 -7.6 FM Ergoldsbach Echolink 96135
DB0ERG JN68DQ 439.35000 431.75000 -7.6 C4FM Ergoldsbach
DB0PR JO43WX 439.35000 431.75000 -7.6 FM Armstedt 67 Hz Subaudio
DB0PER JO53WB 439.35000 431.75000 -7.6 FM Perleberg Echolink: EL#248625
DB0PR JO43WX 439.35000 431.75000 -7.6 C4FM Armstedt
DB0FIB JO60LK 439.35000 431.75000 -7.6 FM

Fichtelberg/

Sachsen

 FM / SVX-Link Node 955615
DB0FIB JO60LK 439.35000 431.75000 -7.6 FM

Fichtelberg/

Sachsen

 FM / SVX-Link Node 955615
DB0NR JO40VU 439.35000 431.75000 -7.6 FM Bad Hersfeld
DB0LD JN49TH 439.35000 431.75000 -7.6 FM Künzelsau
DM0FG JN49IH 439.36250 431.76250 -7.6 FM Wiesloch
DB0EIS JO40AU 439.36250 431.76250 -7.6 FM Siegen-Eisern

Rufton: 1750 Hz,

CTCSS 67,0 Hz
DB0OVL JN68CM 439.37500 431.77500 -7.6 C4FM Landshut

CTCSS 67,0 Hz

Status:

https://projekt-pegasus.net/db0ovl-status/
DB0OVL JN68CM 439.37500 431.77500 -7.6 FM Landshut CTCSS 67,0 Hz
DB0HAA JO31SI 439.37500 431.77500 -7.6 FM Hagen
DB0PX JO40GD 439.37500 431.77500 -7.6 FM Eschborn
DB0CU JO43IU 439.37500 431.77500 -7.6 FM Cuxhaven

Echolink 7048 (DL0CUX)

67,0 Hz
DB0ABA JN59GT 439.37500 431.77500 -7.6 FM Wuestenbuch

mit Tonruf öffnen,

Echolink Node 330854
DB0DBR JO54WC 439.37500 431.77500 -7.6 FM Bad Doberan
DB0ETB JO51PA 439.37500 431.77500 -7.6 FM Weimar Ettersberg
DB0LC JN47WN 439.37500 431.77500 -7.6 FM

Scheidegg

im Allgäu

ctcss 123,0;

Echolink 340877
DB0LC JN47WN 439.37500 431.77500 -7.6 DMR

Scheidegg

im Allgäu

 TS1 ist im Netz.
DB0MIN JO42KH 439.37500 431.77500 -7.6 FM Minden 1750 Hz
DB0HM JN48IV 439.37500 431.77500 -7.6 FM Fachhochschule Pforzheim
DO0SRE JO31OO 439.38750 431.78750 -7.6 DStar Recklinghausen qrv: XLX Reflektor
DB0KL JN39VK 439.38750 431.78750 -7.6 DMR Kaiserslautern Multimode C4FM / DMR
DB0KL JN39VK 439.38750 431.78750 -7.6 C4FM Kaiserslautern Multimode C4FM / DMR
DB0RNG JO43UA 439.38750 431.78750 -7.6 FM Drögenbostel
DB0RBB JN48MQ 439.38750 431.78750 -7.6 FM Böblingen Echolink: 1990
DB0CT JO40LD 439.40000 431.80000 -7.6 FM Hanau 88,5 Hz
DB0CT JO40LD 439.40000 431.80000 -7.6 C4FM Hanau 88,5 Hz
DB0EMS JO32SU 439.40000 431.80000 -7.6 FM Sögel CTCSS 123 Hz
DB0WOS JN68SU 439.40000 431.80000 -7.6 FM

Kreuzberg,

Freyung
DB0HW JO51GT 439.40000 431.80000 -7.6 FM

Bad Harzburg

- Torfhaus
DB0GRZ JO71LD 439.40000 421.80000 -17.6 FM

Görlitz

(Landeskrone)
DB0ANU JN59GG 439.40000 431.80000 -7.6 FM Ansbach Tonruf 1750Hz
DB0DM JN57IV 439.40000 431.80000 -7.6 FM Mauerstetten
DB0HZL JO53JQ 439.40000 431.80000 -7.6 FM Ratzeburg Echolink
DO0SMG JO64TN 439.40000 431.80000 -7.6 FM

Sagard Hoch

Seelow
DB0NAU JO62KO 439.40000 431.80000 -7.6 FM Nauen außer Betrieb
DB0LHR JN38WI 439.40000 431.80000 -7.6 FM Lahr

APRS-Client,

Echolink,

HAMNET-Knoten,

Packet-Knoten
DB0MUH JO30QV 439.40000 431.80000 -7.6 FM Much Subaudio 67Hz
DB0AER JO60LQ 439.40000 431.80000 -7.6 FM Auerbach
DB0HRF JO40FF 439.41250 431.81250 -7.6 C4FM

Feldberg /

Taunus
DM0ET JN59KT 439.41250 431.81250 -7.6 DMR

Frensdorf b.

Bamberg
DB0EP JN39TE 439.41250 431.81250 -7.6 FM

Pirmasens

(Pfalz)

 kein CTCSS
DB0EP JN39TE 439.41250 431.81250 -7.6 C4FM

Pirmasens

(Pfalz)

 kein CTCSS
DB0ED JN58WH 439.41250 431.81250 -7.6 FM Erding

Echolink Node 807790,

CTCSS 67 Hz
DB0RV JN47TT 439.41250 431.81250 -7.6 DMR

Berg bei

Ravensburg
DB0HTV JO40HD 439.42500 431.82500 -7.6 DMR Frankfurt Main DMRPlus
DB0GK JN49MA 439.42500 431.82500 -7.6 FM

Hohenhaslach -

Hohe Reute
DB0KB JO41PU 439.42500 431.82500 -7.6 FM Köterberg
DB0AMB JN59NB 439.42500 431.82500 -7.6 FM

Nennslingen

Burgsalach

 Echolink EL#233842
DB0SP JO62NK 439.42500 431.82500 -7.6 FM Berlin-Wannsee Echolink #255413
DB0SKF JN48EK 439.43750 431.83750 -7.6 FM Freudenstadt
DB0MOT JO40FF 439.43750 431.83750 -7.6 DStar

Feldberg /

Taunus
DB0CJ JN59WK 439.43750 431.83750 -7.6 DMR Amberg DMR ID: 262872
DB0IL JO54CH 439.43750 431.83750 -7.6 FM Kiel C4FM/FM
DB0RTN JO43QC 439.43750 431.83750 -7.6 FM

Rotenburg/

Wümme
DB0RTN JO43QC 439.43750 431.83750 -7.6 C4FM

Rotenburg/

Wümme

 Linkverbund DL-NORDWEST
DB0IL JO54CH 439.43750 431.83750 -7.6 C4FM Kiel C4FM/FM
DB0NJ JN58TE 439.43750 431.83750 -7.6 DMR

München

Freimann
DO0ERZ JO60JQ 439.43750 431.83750 -7.6 DMR

Thalheim/

Sachsen -

Tabakstanne

 Brandmeister Netz
DB0EHS JO72HD 439.45000 431.85000 -7.6 DMR Eisenhüttenstadt
DB0FHC JO50LG 439.45000 431.85000 -7.6 DMR Hochschule Coburg DMR-ID: 262878
DB0HRF JO40FF 439.45000 431.85000 -7.6 DStar Feldberg / Taunus
DM0HMB-B JO53AN 439.45000 431.85000 -7.6 DStar HH-Mitte D-Star
DB0WO JO33RF 439.45000 431.85000 -7.6 DStar Leer
DB0BS JO31OL 439.45000 431.85000 -7.6 DStar Bochum

XLX518C Open-Star

Multiprotocol voreingestellt
DB0AMK JO52XN 439.45000 431.85000 -7.6 DStar Tangermünde DCS120 DL-Ost
DB0RVB JO51GO 439.45000 431.85000 -7.6 DMR Bad Sachsa

CTCSS: 88,5Hz

DMR-ID: 262303
DB0DOS JO42AE 439.45625 431.85625 -7.6 DStar Bad Iburg
DB0ERK JO31CC 439.45625 431.85625 -7.6 DStar Wegberg CTCSS 94,8 Hz
DB0DF JO62RM 439.46250 431.86250 -7.6 DStar Berlin City
DM0HHW-B JO53AN 439.46250 431.86250 -7.6 DStar

Hamburg -

Wandsbek
DB0IZ-B JO43RV 439.46250 431.86250 -7.6 DStar Krempermoor DStar/E 397857
DB0DF-B JO62RM 439.46250 431.86250 -7.6 DStar Berlin
DB0ERZ JO60HK 439.46250 431.86250 -7.6 DMR Eibenstock Brandmeister Netz
DB0DON JN58JR 439.46875 431.86875 -7.6 DStar Donauwörth
DM0LEI JO61FI 439.47500 431.87500 -7.6 DStar Leipzig
DB0WZ JN49WS 439.47500 431.87500 -7.6 DMR Würzburg DMR+ ID: 262849
DB0WZ-B JN49WS 439.47500 431.87500 -7.6 DStar Würzburg
DB0LAM JO52AD 439.47500 431.87500 -7.6 DMR

Achtum,

Hildesheim

 DMR+
DB0RDH JN68KW 439.47500 431.87500 -7.6 DStar Grandsberg
DB0HGW-B JO64QC 439.47500 431.84500 -7.6 DStar Greifswald
DB0AFZ-B JO41RG 439.47500 431.87500 -7.6 DStar Baunatal
DB0EIS JO40AU 439.48120 431.88120 -7.6 DStar Siegen-Eisern
DB0DLR JO52GH 439.48750 431.88750 -7.6 DStar

Braunschweig

Flughafen DLR
DB0BRB JO62GJ 439.48750 431.88750 -7.6 DMR

THB/Brandenburg

an der Havel
DB0TIT JN47CW 439.48750 431.88750 -7.6 DStar

Titisee-

Neustadt
DB0HRC JO61AG 439.48750 431.88750 -7.6 DMR

Oebles -

Schlechtewitz

 DMR ID 262009
DM0SL JO44SM 439.48750 431.88750 -7.6 C4FM Schleswig
DB0SPN JO71ER 439.48750 431.88750 -7.6 DMR Cottbus DMR-Plus- ID: 2621140
DB0EG JO32PC 439.48750 431.88750 -7.6 DMR Schöppingen

Hytera Relais

DCS4007 NRW
DB0HFT-B JO43JB 439.48750 431.88750 -7.6 DStar Bremen
DB0USD JO41TP 439.48750 431.88750 -7.6 DMR Uslar

ID: 262370 / BM262 mit D+

als TG9262 und TG99
DB0WTV JO43BM 439.49375 431.89375 -7.6 DStar Wilhelmshaven
DB0NU JO50IE 439.50000 431.90000 -7.6 DStar Altenstein
DB0SBX JO60IT 439.50000 431.90000 -7.6 DStar Hohenstein
DB0XX JO52MF 439.50000 431.90000 -7.6 DMR Helmstedt DMR-ID 262306
DB0SN JO41VL 439.50000 431.90000 -7.6 DStar

Hoher Hagen

Str.; 37127

Dransfeld

ID: 262342 /

BM262 mit D+ auf TG99
DB0POB JN58QP 439.50000 431.90000 -7.6 DStar Pobenhausen DStar 28175
DB0CI JN48EF 439.50000 431.90000 -7.6 DStar Schramberg
DB0CI JN48EF 439.50000 431.90000 -7.6 DMR Schramberg DMR-ID: 262732
DB0LY JO63PF 439.50000 431.90000 -7.6 DStar Lychen
DB0OTV JO31HG 439.50000 431.90000 -7.6 C4FM Meerbusch CTCSS 123
DB0SN JO41VL 439.50000 431.90000 -7.6 DMR

Hoher Hagen

Str.; 37127

Dransfeld

 DMR-ID: 262342
DB0HWR JN39JN 439.50000 431.90000 -7.6 C4FM Weiskirchen

Der Repeater arbeitet im reinen Digitalbetrieb.

Die Anbindung an das Wires-X Netz

wird zeitnah umgesetzt.
DB0ORT JN48BN 439.50625 431.90625 -7.6 DStar Rodeck
DB0RES JO31ES 439.51250 431.91250 -7.6 C4FM Rees
DB0MDX JO40JT 439.51250 431.91250 -7.6 DStar

Marburg

Lahn

meist mit DCS001K

(Hessen-Reflector) verbunden
DB0HPA JO43SV 439.51250 431.91250 -7.6 DMR Laegerdorf
DB0NGU JO32KL 439.51250 431.91250 -7.6 DStar Uelsen
DO0FWH JO62AG 439.51250 431.91250 -7.6 DStar Stresow
DB0HRM JO41WE 439.52500 431.92500 -7.6 DStar Hoher Meißner
DM0RDH JN69HA 439.52500 431.92500 -7.6 DMR

Schwemm,

Wiesenfelden

 CTCSS 67,0Hz
DB0EW JN39MF 439.52500 431.92500 -7.6 DMR Saarbrücken

DMR-ID: 262588

Brandmeister
DM0PX JO40GD 439.52500 431.92500 -7.6 DMR Eschborn
DB0HHO JO53DP 439.52500 431.92500 -7.6 DMR HH-Großhansdorf DMR/FM
DM0MOT JO62PN 439.52500 431.92500 -7.6 DMR

Berlin -

Tegel

 DMR-ID: 262100
DB0FRB JN38WA 439.52500 431.92500 -7.6 DStar

Freiburg

im Breisgau
DB0DAM JO42CN 439.52500 431.92500 -7.6 DStar Dammer Berge
DB0ERZ JO60HK 439.52500 431.92500 -7.6 DStar Eibenstock
DB0VOX JN59MK 439.52500 431.92500 -7.6 DStar Nürnberg FMT
DB0DBN JO30OQ 439.53125 431.93125 -7.6 DStar

Königswinter

Oelberg
DB0BHN JO43GN 439.53750 431.93750 -7.6 DStar Bremerhaven
DB0DTR JN39GS 439.53750 431.93750 -7.6 DMR Trierweiler
DM0GER JN58QC 439.53750 431.93750 -7.6 DMR

München

Germering

DMR-ID 262835

Brandmeister /

MMDVM-Relais
DB0OBO JO42RD 439.53750 431.93750 -7.6 DMR

Hameln -

Bad Münder

 DMR-ID 262301
DB0KK JO62RM 439.53750 431.93750 -7.6 DMR

Berlin-

Lichtenberg

 CC 1, QRV ab 6.5.2018
DB0DDE JO31ML 439.53750 431.93750 -7.6 DStar Essen
DB0FLW JO61EH 439.53750 431.93750 -7.6 DMR Leipzig DMR ID: 262905
DB0ZRB JN48MS 439.53750 431.93750 -7.6 DMR Gerlingen - Schillerhoehe Brandmeister
DB0FWS JO50CB 439.53750 431.93750 -7.6 DStar Schweinfurt
DB0SEN JO31RU 439.54370 431.94370 -7.6 DMR Senden
DM0MW JO60LX 439.55000 431.95000 -7.6 DStar Mittweida
DB0SHA JO42UJ 439.55000 431.95000 -7.6 DStar Hannover ircDDB_GW-20151116
DB0AAT JN67HU 439.55000 431.95000 -7.6 DMR

Hochberg,

Traunstein

ColorCode: 1,

TS1: DMRMarc,

TS2: DMRplus
DB0WOL JO62XR 439.55000 431.95000 -7.6 DMR Bad Freienwalde Wollenberg DMR-ID: 262111
DM0LUE JO53JT 439.55000 431.95000 -7.6 DStar Lüdersdorf
DB0ADB JN59KV 439.55000 431.95000 -7.6 DStar Bamberg
DB0CHV-B JO43IU 439.55000 431.95000 -7.6 DStar Cuxhaven
DB0PBS JO41JR 439.55000 431.95000 -7.6 DStar Paderborn
DB0WIM JN49CD 439.56250 431.96250 -7.6 C4FM Herxheim

Versuchsbetrieb,

APRS Digi 144.8 MHz

am gleichen Standort
DB0WIM JN49CD 439.56250 431.96250 -7.6 DStar Herxheim
DB0WIM JN49CD 439.56250 431.96250 -7.6 FM Herxheim
DB0KH JO40RV 439.56250 431.96250 -7.6 DStar

Schotten -

Rimberg
DB0FS JO43XO 439.56250 431.96250 -7.6 DMR HH-Lokstedt

DMR-ID: 262220,

Timeslot 2, TG 9: lokal ,

TG 8: regional

(DB0FS/DB0ZE im Verbund),

über TG 26221 erreichbar
DB0MYK-B JO30OJ 439.56250 431.96250 -7.6 DStar Gänsehals Eifel
DB0OHA JO51EP 439.56250 431.96250 -7.6 DStar Herzberg CTCSS 88,5 Hz RPTR DTMF 28082
DB0WV JN47QT 439.56250 431.96350 -7.6 DStar

Höchsten

(Ilmensee)
DB0FEU JN59DD 439.57500 431.97500 -7.6 FM Feuchtwangen
